MODE: The following backlight modes are available:
• O: The backlight will never come ON.
• Sense: The backlight will only come ON if the light sensor detects low
light conditions. See also“SENSE LEVEL” discussion below.
• On: The backlight will come ON any time a key is pressed.
SENSE LEVEL (Sen Lvl): The point where the backlight comes ON in a
darkened room. To set this level, go to a dim area where you think the
backlight should be activated given such a dark environment condition.
Then, press [ENTER] at “B Light – Sen Lvl” menu. The display will show the
current sensitivity level. An example is below
If such sensitivity level is alright with you, press [ENTER].
Select “YES” to complete the setting of the sensitivity level.
LIBRARY
The HTRC 1 can store a dierent library of default NAD codes for each of
its DEVICE SELECTOR “pages.” If the original default library does not control
your NAD CD player, DVD player, or other component, follow the procedure
below to change the library code. Please refer as well to the table below for
a list of uploaded NAD Library Codes.
Example: Load NAD DVD Player T 585 library codes to HTRC 1’s “DVD”
device.
1 Press [DVD] in the DEVICE SELECTOR page.
2 Press and hold [TUNER (10+/SETUP)] and [ENTER] buttons. Use [ ] to
scroll to “Library”.
3 Press [ENTER].
4 The library code for NAD T585 is “600”. Use [ ] to toggle to “600”. Press
[ENTER].
5 Use [ ] to select between “No” (desired library code is not
uploaded) and “Yes” (desired library code is uploaded and saved to the
applicable device page.
NOTE
Instead of scrolling through the library list, you can also key-in directly
the library code based on the list of Library Codes below.
LIBRARY CODE
NAD PRODUCT
DESCRIPTION
LIBRARY CODE
NAD PRODUCT
DESCRIPTION
100
Receiver/Processor
(Discrete ON/OFF)
301 L75, L76 Tuner
101
Receiver/Processor
(Toggle ON/OFF)
302 L70 Tuner
102 S170 303 L53 Tuner
103 L75 304 L73 Tuner
104
Second Zone
Commands
305 C425
105 L70 306 C445
106 L76 307 Txx5 Series Tuner
107 118 400 Tape Deck B
108 L53 401 TAPE Deck A
109 L73 500 TV 280
110
Stereo Receiver/
Amplier
501 MR13
111 Stereo Second Zone 502 MR20
112 Txx5 Series 503 PMR45
200 CD Player 600
T535, T562, T585,
M55
201 CD Player (old) 601 T550, L55
202 5170, 5240, 5340 602
T512, T531, T532,
T571, T572
203 5325 603 L70, L73 DVD
204 5060 604 L56
205 M5 605
T513, T514, T515,
T524, T533, T534
300 Tuner 606 L53 DVD
LEARN
This function allows you to learn IR commands from another remote.
Example: Learning “MENU” function from a TV remote control into the
MENU button of HTRC 1’s TV device.
Begin by positioning the HTRC 1 “nose-to-nose” with the source remote so
that the two devices’ infrared windows are about 2 inches apart.
1 Press [TV] in the DEVICE SELECTOR page.
2 Press and hold [TUNER (10+/SETUP)] and [ENTER] buttons. Use [ ] to
scroll to “Learn”.
OPERATION
USING THE HTRC 1 REMOTE CONTROL
38
