Sub-trim is an electronic trim that is available for
each of the six channels. Sub-trim is particularly
useful as it allows the mechanical trim levers to be
returned to their neutral positions by adjusting
/changing the servo’s neutral position electronically,
without the need to mechanically adjust the specific
control linkage. This allows the same mechanical
trim lever settings between the five models you can
control with this radio system. Sub-trim can also
allow additional trim travel when mechanical trims
do not provide enough movement.
Note: It is recommended to use as little subtrim as
possible for adjustment. If more that 20–30 points
are required, is it suggested that a mechanical
linkage adjustment be performed.
1. Turn on the transmitter.
2. Press the SCROLL and INCREASE buttons
simultaneously to enter the function mode.
3. Press the SCROLL button until “SB-Trim”
appears on the screen.
4. Press the CHANNEL button until the desired
channel appears on the screen.
5. Press the INCREASE or DECREASE button to
establish the desired amount of sub-trim.
6. Press the SCROLL button to access the Travel
Adjustment function.
7. To exit, press the SCROLL and INCREASE
buttons simultaneously.
SUB-TRIM
7.4
CHAPTER 7: FUNCTIONS (FUNCTION MODE)
•
Helicopter
Press the SCROLL
button until “SB-TRIM”
appears on the screen.
Press the CHANNEL button
until the desired channel
appears on the screen.
Press the INCREASE or
DECREASE button to
adjust the sub-trim value.
