XP662 MANUAL Helicopter
HO = ALL SERVOS HOLD
0.3 = 1/3 SECOND TIME DELAY
0.5 = 1/2 SECOND TIME DELAY
1.0 = 1 SECOND TIME DELAY
HO
FST
Press either the INCREASE or
DECREASE buttons to select the
desired time delay.
HOLD
.3 SECONDS
.5 SECONDS
1.0 SECONDS
1. After accessing the Fail-Safe function, it is now
time to adjust the fail-safe time presets.
2. Select among the three time delays (.3, .5, or 1.0
seconds) by pressing either the (+) or (-) keys
until the desired setting appears on the screen.
CHAPTER 6: FUNCTIONS (SYSTEM MODE)
•
Helicopter
1. Press the SCROLL button until FSM appears on
the screen.
Note: If Hold position (HO) is selected, this
function/screen will not be present.
2. Set all controls to the desired fail-safe position,
then press the (+) and (-) buttons simultaneously.
A high pitch beep sound will confirm that the
preset positions have been entered.
3. Hold the transmitter sticks in the position that
you want the servos to assume during signal loss
conditions. You can determine fail-safe preset
positions for the other channels by placing the
potentiometers and switches in the positions
that you want them to assume during interference.
4. With the sticks, switches and potentiometers in
the fail-safe positions, press the CHANNEL and
INCREASE keys simultaneously. This will enter
these locations as the fail-safe memory settings.
A high-pitched beep will indicate that this
setting has been stored.
5. To confirm that the input of data was successful,
switch the transmitter OFF. The controls will move
to the input locations. If not, repeat Step 4 again.
6. To exit the Fail-Safe function, press the SCROLL
and INCREASE buttons simultaneously.
Note: These preset positions remain stored in the
transmitter’s memory until both the transmitter
battery pack and the lithium back-up battery have
been removed (or until data reset has been performed).
Therefore, you do not have to reset the fail-safe each
time you fly. Should you want to re-adjust the fail-
safe presets, access the Fail-Safe function and adjust
the presets as you have just done. The transmitter
automatically recalls the settings for
the last fail-safe adjustment.
CL WILL FLASH WHEN FAIL-
SAFE SERVO POSITIONS ARE
ENTERED.
CL
FSM
Press the CHANNEL and INCREASE buttons
simultaneously to store the fail-safe servo presets.
FAIL-SAFE/HOLD FUNCTION IN Z-PCM MODULATION (continued)
6.9
Setting Servo Position Presets
Setting Fail-Safe/Hold Time Delay/Memory In Z-PCM Modulation
