42
XP662 MANUAL Airplane
CHAPTER 7: FUNCTIONS (FUNCTION MODE)
•
Airplane
1. Follows Steps 1 through 4 as on the previous page.
2. Press the CHANNEL button until “MIX EFS”
appears on the screen.
3. Press the INCREASE or DECREASE button until the
desired switch designation appears on the screen.
4. Press the SCROLL button to access the
differential function if flaperons or delta-wing
types are activated in the system mode. If flaperons
are not activated, pressing the
SCROLL
button
will access the flap-to-elevator offset function.
5. To exit, press the SCROLL and INCREASE
buttons simultaneously.
Accessing the Elevator-to-Flap Mixing Switch Function
ELEVATOR-TO-FLAP MIXING (continued)7.7
MIX
EFS
ON
MIXING SWITCH
ON = MIXING IS ALWAYS ON
S = LANDING GEAR SWITCH
E = ELEVATOR DUAL RATE
F0 = FLAP SWITCH
INDICATES THE ELEVATOR-TO-FLAP
MIXING SWITCH FUNCTION
N
CHANNEL
SCROLL
INCREASE
DECREASE
ENTER
Press the CHANNEL button until
“EFS”appears on the screen.
Press the INCREASE or DECREASE
button until the desired switch designation
appers on the screen.
Elevator-to-Flap Mixing Switch Selection
