Listening to your system 06
57
En
English
Français
Deutsch
Nederlands
Italiano
Español
• If the source is Dolby Digital, DTS, or Dolby
Surround encoded, the proper decoding
format will automatically be selected and
shows in the display.
1
With two channel sources, you can select from:
• 2 Pro Logic IIx MOVIE – Up to 7.1
channel (surround back) sound, especially
suited to movie sources
• 2 Pro Logic IIx MUSIC – Up to 7.1
channel (surround back) sound, especially
suited to music sources
2
• 2 Pro Logic IIx GAME – Up to 7.1 channel
(surround back) sound, especially suited to
video games
• 2 Pro Logic – 4.1 channel surround
sound (sound from the surround speakers
is mono)
• WIDE SURROUND MOVIE – Up to 7.1
channel (front wide) sound, especially
suited to movie sources
3
• WIDE SURROUND MUSIC – Up to 7.1
channel (front wide) sound, especially
suited to music sources
3
• Neo:6 CINEMA – Up to 7.1 channel
(surround back) sound, especially suited to
movie sources
• Neo:6 MUSIC – Up to 7.1 channel
(surround back) sound, especially suited to
music sources
4
• NEURAL SURR – Up to 7.1 channel
(surround back) sound, especially suited to
music sources
5
• 2 Pro Logic IIz HEIGHT – Up to 7.1
channel (front height) sound
6
With multichannel sources, if you have
connected surround back, front height or front
wide speakers, you can select (according to
format):
• 2 Pro Logic IIx MOVIE – See above
• 2 Pro Logic IIx MUSIC – See above
• Dolby Digital EX – Creates surround back
channel sound for 5.1 channel sources and
provides pure decoding for 6.1 channel
sources (like Dolby Digital Surround EX)
• DTS-ES – Allows you to hear 6.1 channel
playback with DTS-ES encoded sources
• DTS Neo:6 – Allows you to hear 6.1
channel playback with DTS encoded
sources
• 2 Pro Logic IIz HEIGHT – See above
• WIDE SURROUND MOVIE – See above
• WIDE SURROUND MUSIC – See above
• Straight Decode – Plays back without the
effects above.
Note
1 If the surround back speakers are not connected or V.SB is switched OFF, 2 Pro Logic IIx becomes 2 Pro Logic II
(5.1 channel sound).
2 When listening to 2-channel sources in Dolby Pro Logic IIx Music mode, there are three further parameters you can
adjust: C.WIDTH, DIMENSION and PANORAMA. See Setting the Audio options on page 67 to adjust them.
3 This mode can only be selected when Speaker System is set to Normal(SB/FW).
4 When listening to 2-channel sources in Neo:6 Cinema or Neo:6 Music mode, you can also adjust the center image
effect (see Setting the Audio options on page 67).
5 NEURAL SURR can be selected for 2-channel signals for which the input signal is PCM (48 kHz or less), Dolby Digital,
DTS or analog 2-channel sources.
6• This mode can only be selected when Speaker System is set to Normal(SB/FH).
• When listening in 2 Pro Logic IIz HEIGHT mode, you can also adjust the HEIGHT GAIN effect (see Setting the
Audio options on page 67).
