– 82 –
Specifications
Amplifier
Output Power (IEC 268-3/DIN):
40 W (20 W + 20 W) at 4 Ω (10% THD)
Audio input sensitivity/Impedance (at 1 kHz)
LINE IN : 260 mV/54 kΩ (at “LEVEL 1”)
640 mV/54 kΩ (at “LEVEL 2”)
Audio output level/Impedance (at 1 kHz)
LINE OUT : 215 mV/3.9 kΩ
Speakers/Impedance: 4 Ω to 16 Ω
Tuner
FM tuning range : 87.50 MHz to 108.00 MHz
AM (MW/LW) tuning range :
MW : 522 kHz to 1 629 kHz
LW : 144 kHz to 288 kHz
CD player
CD Capacity : 1 CD
Dynamic range : 88 dB
Signal-to-noise ratio : 95 dB
Wow and flutter : Immeasurable
Hard Disc Drive (HDD)
Data storage : 10 Gbytes
Recording system : Linear PCM
AAC 128 kbps
AAC 96 kbps
Recording length:
Linear PCM : Approx. 15 hours
AAC 128 kbps : Approx. 160 hours
AAC 96 kbps : Approx. 220 hours
General
Operating temperature : 5˚C to 35˚C
Operating altitude : –300 m to +3 048 m
Power requirement : AC 230 V , 50 Hz
Power consumption : 60 W (in operation)
1.4 W (on standby: with display
off)
1.6 W (on standby: with display on)
Dimensions (W/H/D) (approx.) :
150 mm x 237 mm x 274 mm
Mass (approx.) : 4.8 kg
Supplied accessories
See page 6.
Design and specifications are subject to change without
notice.
IMPORTANT: The manufacturer assumes no
liability whatsoever for any damage resulting from
missed opportunity or accidental erasure due to
malfunctioning of the unit or due to trouble in the
unit, such as fatal collapse of the hard disk drive
itself.
• Since the HDD has its lifetime, it is strongly
recommended to make a copy of your important
recordings, and keep it using other recording devices.
