Dual XDVDN8190 CD Player User Manual



XDVDN8190 OPERATION
68
iPod Operation - OSD Overview (Optional)
Shuffle
Touch the
icon to shuffle the songs in the current group.
Group Select Mode
Allows selection of songs by various groups.
Direct Select Keyboard
Touch the
icon to display a numeric keyboard for song selection.
Return/Back
Touch
to return to the previous group/menu.
Scan Mode
Pressing this button will scan through all songs for 10 seconds.
Fast Forward
Touch the
icon to fast forward at 2x speed.
Rewind
Touch the
icon to rewind at 2x speed.
Page Up
Touch the
icon to see the next 6 songs in the folder.
Page Down
Touch the
icon to see the previous 6 songs in the folder.
Album
Displays the name of the album for the current song.
Stop
Touch the
icon to stop the song where it is.
Play / Pause
Touch the
icon to temporarily stop or resume playback.
Volume Indicator
Indicates current volume level, controlled by rotary encoder.
Loudness Indicator
Touch screen here to enter the Audio Setup Menu.
EQ indicator
Touch screen here to enter the Audio Setup Menu.
Elapsed Time Indicator
Shows the elapsed time of the current song.
9
11
10
12
13
14
15
16
17
18
19
20
21
22
23
24
