45
GB
Amplifier Operations
The following options are available in each
menu. For details on navigating through
menus, see page 44.
Overview of the menus
Menu
[Display]
Parameters
[Display]
Settings Initial
setting
AUTO CAL
[AUTO CAL]
(page 37)
Auto calibration
[A.CAL START]
Calibration type
a)
[CAL TYPE]
FULL FLAT, ENGINEER
FRONT REF, OFF
FULL FLAT
Position
a)
[POSITION]
POS. 1, POS. 2, POS. 3 POS. 1
Naming inputs
a)
[NAME IN]
For details, see “To name the
position” (page 38).
LEVEL
[LEVEL]
(page 49)
Test tone
a)c)
[TEST TONE]
OFF, FIX xxx
b)
, AUTO xxx
b)
OFF
Phase noise
a)c)
[P. NOISE]
OFF, FL/SR, SL/FL, SB/SL, SBL/SL,
SBR/SBL, SR/SB, SR/SBR, SR/SL,
FR/SR, FR/SL, FL/FR, CNT/FR,
FL/CNT
OFF
Phase audio
a)c)
[P. AUDIO]
OFF, FL/SR, SL/FL, SB/SL, SBL/SL,
SBR/SBL, SR/SB, SR/SBR, SR/SL,
FR/SR, FR/SL, FL/FR, CNT/FR,
FL/CNT
OFF
Front left speaker level
c)
[FL LEVEL]
FL –10 dB to FL +10 dB
(0.5 dB per step)
0 dB
Front right speaker level
c)
[FR LEVEL]
FR –10 dB to FR +10 dB
(0.5 dB per step)
0 dB
Center speaker level
c)
[CNT LEVEL]
CNT –20 dB to CNT +10 dB
(0.5 dB per step)
0 dB
Surround left speaker level
c)
[SL LEVEL]
SL –20 dB to SL +10 dB
(0.5 dB per step)
0 dB
Surround right speaker level
c)
[SR LEVEL]
SR –20 dB to SR +10 dB
(0.5 dB per step)
0 dB
Surround back speaker level
c)
[SB LEVEL]
SB –20 dB to SB +10 dB
(0.5 dB per step)
0 dB
Surround back left speaker level
c)
[SBL LEVEL]
SBL –20 dB to SBL +10 dB
(0.5 dB per step)
0 dB
Surround back right speaker
level
c)
[SBR LEVEL]
SBR –20 dB to SBR +10 dB
(0.5 dB per step)
0 dB
Subwoofer level
c)
[SW LEVEL]
SW –20 dB to SW +10 dB
(0.5 dB per step)
0 dB
Dynamic range compressor
a)
[D. RANGE]
COMP. MAX, COMP. STD,
COMP. AUTO, COMP. OFF
COMP. AUTO
continued
