16
US
Getting Started – BASIC –
This hookup is the basic connection of the system to the speakers and TV. For other TV connections,
see page 27. For other component connection, see page 31.
To accept progressive signals, see page 29.
Refer to the connection diagram below, and read the additional information from 1 to 4 on the
following pages.
Step 2: Connecting the System and TV
AM
COAXIAL
FM
75
SPEAKER
FRONT R FRONT L SUR R SUR LCENTER WOOFER
COMPONENT VIDEO OUT
TV/VCR2
TV/VCR2
TV/VCR1
MONITOR OUT
COMPONENT VIDEO IN
YP
B
/C
B
P
R
/C
R
YP
B
/C
B
P
R
/C
R
RLAUDIO IN VIDEO INDIGITAL IN
COAXIAL
OPTICAL
DIGITAL
IN
RLAUDIO IN VIDEO IN
VIDEO
S VIDEO
(DVD ONLY)
XM
DIR-T1
OUT
(DVD ONLY)
SPEAKER
R
AUDIO
OUT
L
VIDEO
IN
SUR L SUR R
SS-TS56W
AM loop antenna (aerial)
Subwoofer
AC power cord
(mains lead)
FM wire antenna
(aerial)
TV
Front speaker (R)
Center speaker
Front speaker (L)
Surround speaker (L)Surround speaker (R)
AC power cord
(mains lead)
A
B
IR transmitter
