Displays & Controls
Back Panel
All the terminals on the back panel are explained and/or referenced here.
1 DIGITAL IN terminals (see page 21–22)
Use these terminals to input the signal from a
DVD, CD player or any other kind of digital
player. To be able to play Dolby Digital and
other surround soundtracks you need to make
digital connections. To do this use the digital
terminals here. If you don't connect as per the
default settings (see page 22) you need to
complete "Assigning the Digital Inputs" (see
page 76).
2 DIGITAL OUT terminals (see page 21)
Use these terminals to output a digital signal to
a DVD-R, CD-R, MD recorder or any other kind
of digital recorder.
3 CONTROL IN/OUT terminal (see page
71)
You can use this jack to hook up other
PIONEER equipment, that has a CONTROL
terminal, so that you can control them all by
pointing the remote control(s) at one remote
sensor.
4 Radio antenna terminals (see page 23)
Hook up antennas for the radio tuner built into
the receiver here.
5 MONITOR OUT terminals (connect a TV
or monitor here, see page 15)
Use these terminals to output a video signal to
a TV or monitor.
6 PRE OUT analog terminals (connect an
amplifier here, see page 67)
Use these terminals to output the audio signal
from this amplifier to a different amplifier if
that's how you choose to set up your system.
7 COMPONENT VIDEO MONITOR OUT
terminals (connect a TV or monitor
here, see page 15)
Use these terminals to output the video signal
from the COMPONENT VIDEO IN terminals to
your TV. See #13 for more information.
