26 DRX9575Rz
DSP operations
DSP control function
If the DSP (DPH7500z), sold separately, is con-
nected to this unit using the CeNET cable, all
the functions of the DSP can be controlled.
DSP functions
There are 2 modes available in DPH7500z, easy
mode and professional mode. Choose one of them
and adjust the sound field and the sound quality.
• Functions common to each mode:
Spectrum analyzer display, auto loudness, etc.
• Easy mode:
Adjustment using the graphic equalizer function
and the DSP function.
• Professional mode:
Adjustment using the space equalizer function
and the parametric equalizer function.
∗ When the easy mode is selected, adjustment for
the professional mode cannot be made. On the
contrary, when the professional mode is selected,
adjustment for the easy mode cannot be made.
∗ For details on functions of each mode, refer to the
owner’s manual supplied with the DPH7500z.
∗ Hereafter the graphic equalizer is referred to as a
G.EQ, the space equalizer referred to as S.EQ and
the parametric equalizer referred to as P.EQ.
Operations common to each mode
Enjoying the spectrum analyzer
This unit can display the spectrum analyzer
patterns. There are 6 spectrum analyzer patterns.
1. Press DISP button " to select the spectrum
analyzer display.
2. Each time you press and hold DISP button
" for 1 second or longer, the spectrum
analyzer patterns are switched.
Setting the sensitivity of the
spectrum analyzer
∗ The factory default setting is “MID”.
1. Press ADJ button & to switch to the
adjustment selection display.
2. Press the right or left side of SEARCH button
2 to select “ANA SENS”.
3. Press ENT button (.
4. Turn the Rotary knob 3 clockwise or
counterclockwise to set the sensitivity of the
spectrum analyzer.
You can choose one of “LOW”, “MID” or “HIGH”
for the sensitivity of the spectrum analyzer.
Auto store
Auto store selects 6 TV stations automatically and
stores each one into a preset memory.
If there are not 6 stations with good reception,
stations previously stored in memory remain and
only the strong stations are stored into memory.
1. Press BAND button 4 and select the desired
TV band. (TV1 or TV2)
2. Press S button # to display the subdisplay.
3. Press and hold the number “2” of Preset
buttons $ for 2 seconds or longer. The
stations with good reception are automatically
stored to preset buttons.
Preset scan
Preset scan allows the user to view each preset
position before it automatically advances to the
next preset. This function is useful for searching
for desired TV station in memory.
1. Press S button # to display the subdisplay.
2. Press the number “1” of Preset buttons $.
3. When the desired channel is received, press
the number “1” of Preset buttons $ again.
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
1. Press ADJ button & to switch to the
adjustment selection display.
2. Press the right or left side of SEARCH button
2 to select “TV DIVER”.
3. Press ENT button (.
4. Turn the Rotary knob 3 clockwise to set to
“ON” or counterclockwise to set to “OFF”.
● ON:
Sets reception emphasizing the visual.
● OFF:
Sets the diver setting to OFF.
5. Press ENT button (.
6. Press ADJ button & to return to the previous
mode.
TV Operations
