DRX9575Rz 17
CAUTION
Be careful not to get your fingers caught when
opening and closing the SLOPING CONSOLE.
2. Remove the CD and press OPEN button 9
to close the SLOPING CONSOLE.
Notes:
• Be sure to close the SLOPING CONSOLE after
removing the CD.
• The SLOPING CONSOLE closes automatically 30
seconds after removing the CD.
∗ If a CD (12 cm) is left in the ejected position for 15
seconds, the CD is automatically reloaded. (Auto
reload)
∗ 3
"
CDs (8 cm) are not auto reloaded. Be sure to
remove it when ejected.
Notes:
• If you force a CD into before auto reloading,
this can damage the CD.
• The radio mode is selected automatically 4 sec-
onds after Eject button
9
is pressed.
Selecting a track
● Track-up
1. Press the right side of SEARCH button 2 to
move ahead to the beginning of the next track.
2. Each time you press the right side of SEARCH
button 2, the track advances ahead to the
beginning of the next track.
● Track-down
1. Press the left side of SEARCH button 2 to
move back to the beginning of the current track.
2. Press the left side of SEARCH button 2 twice
to move to the beginning of the previous track.
Fast-forward/fast-backward
● Fast-forward
Press and hold the right side of SEARCH button
2 for 1 second or longer.
● Fast-backward
Press and hold the left side of SEARCH button
2 for 1 second or longer.
Top function
The top function resets the CD player to the first
track of the disc. Press TOP button 4 to play
the first track (track No. 1) on the disc.
Loading a CD
1. Press OPEN button 9. The SLOPING
CONSOLE opens.
CAUTION
.
Be careful not to get your fingers caught when
opening and closing the SLOPING CONSOLE.
2. Insert a CD into the center of the insertion
slot with the label side facing up. The CD plays
automatically after loading.
Notes:
• Never insert foreign objects into the CD insertion
slot.
• If the CD is not inserted easily, there may be
another CD in the mechanism or the unit may
require service.
• Discs not bearing the mark and CD-ROMs
cannot be played by this unit.
Loading 3
"
(8 cm) compact discs
∗ No adapter is required to play a 3
"
CD.
∗ Insert the 3
"
CD into the center of the insertion slot.
∗ When a 3
"
CD is loaded, “SINGLE” lights in the
display.
3. After loading a CD, the SLOPING CONSOLE
closes automatically.
Notes:
• Note that SLOPING CONSOLE close immediately
after a CD is inserted into CD insertion slot.
• If no CD is loaded in the SLOPING CONSOLE, it
closes after 30 seconds.
Listening to a CD already inserted
Press FUNC button 5 to select the CD mode.
Play starts automatically. If no CD is loaded in
the unit, “NO DISC” appears in the display.
Pausing play
1. Press Play/pause button ( to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press Play/pause button
( again.
Ejecting a CD
1. Press the Eject button 9. The SLOPING
CONSOLE opens and a CD ejects. “EJECT”
appears in the display.
CD Operations
