STR-DA3500ES
4-144-907-43(1)
Additional
Information
Video
There is no picture or an unclear
picture appears on the TV screen.
• Select the appropriate input on the receiver
(page 50).
• Set your TV to the appropriate input mode.
• Move your audio components away from
the TV.
• Assign the video input correctly.
• The input signal should be same as input
when you are up-converting an input
signal with this receiver (page 33).
The image of the COMPONENT VIDEO
OUT is corrupted.
• Video input signals other than 480p
component are not received when signals
are output from the VIDEO jack. Input
480i component video signals.
• When component input signals other than
480p are output, use the COMPONENT
VIDEO MONITOR OUT jack and set
“Resolution” to “DIRECT”.
Recording cannot be carried out.
• Check that the components are connected
correctly (page 25).
• Select the source component using INPUT
SELECTOR (page 50).
The GUI does not appear on the TV
screen.
• Press GUI MODE repeatedly to select
“GUI ON”. Press MENU if the GUI menu
does not appear on the TVscreen.
• Check that the TV is connected correctly.
HDMI
The source sound input to the HDMI
jack is not output from the receiver or
the TV speaker.
• Check the HDMI connection (page 77).
• You cannot listen to the DSD signals of
Super Audio CD by connecting HDMI.
• Depending on the playback component,
you may need to set up the component.
Refer to the operating instructions
supplied with each component.
• Be sure to use a connecting cable for the
HDMI jack corresponding to high speed
(an HDMI version 1.3a, category 2 cable)
when you view images or listen to sound
during a 1080p or Deep Color (Deep
Colour) transmission.
The source image input to the HDMI
jack is not output from the TV.
• Check the HDMI connection (page 77).
• Depending on the playback component,
you may need to set up the component.
Refer to the operating instructions
supplied with each component.
• Be sure to use a connecting cable for the
HDMI jack corresponding to high speed
(an HDMI version 1.3a, category 2 cable)
when you view images or listen to sound
during a 1080p or Deep Color (Deep
Colour) transmission.
continued
