– 5 –
English
See pages in the parentheses for details.
Front Panel
1 VOLUME + / – control (10, 26 – 27)
2 SOUND TURBO button (10)
3 ACTIVE BASS EX. button (10)
4 Remote sensor
5 Sound mode buttons (11)
• ROCK button
• POP button
• CINEMA button
6 CD play mode buttons
• REPEAT button (16)
• PROGRAM button (15, 21)
• RANDOM button (16, 21)
7 PHONES jack (10)
8 CLOCK/TIMER button (9, 28 – 29)
SET button (9, 12, 15, 21)
CANCEL/DEMO button (8, 15, 22)
9 Recording buttons
• REC START/STOP button (24)
• DISC REC START button (25)
• DUBBING button (25)
p
STANDBY/ON button and STANDBY lamp
(9, 16, 29)
q AUX button (10)
Pressing this button also turns on the unit.
w TAPE-A 2 3 button (10, 23 – 24)
Pressing this button also turns on the unit.
e Deck A cassette holder (23)
r 0 EJECT button for deck A (23)
t Display window
y Disc tray
u PRESET PREV. – and NEXT + buttons
4 and ¢ (reverse search/forward search) buttons
(9, 12, 14 – 15, 18, 21 – 22, 28 – 29)
i Disc number buttons (DISC 1, DISC 2, and DISC 3)
(14 – 15, 17, 19 – 20, 25)
Pressing one of these buttons also turns on the unit.
o DISC SKIP button (13, 17)
; 0 (Disc tray open/close) button (13 – 14, 16 – 17)
Pressing one of these buttons also turns on the unit.
Display Window
Display Window
1 S. MODE (SOUND MODE) indicator
2 ACTIVE BASS EX. indicator
3 SOUND TURBO indicator
4 MP3 indicator
5 Tuner operation indicators
• MONO and ST (stereo) indicators
6 Main display
• Shows the source name, frequency, etc.
7 Tape operation indicators
• A/B (operating deck) and (recording)
8 Disc indicators
9 Timer indicators
• (Timer), DAILY (Daily Timer), REC (Recording
Timer), and SLEEP (Sleep Timer) indicators
p Karaoke ( ) and echo ( ) indicators
q Audio level indicator
w PBC indicator
e CD play mode indicators
• REPEAT (ALL/1/CD), PRGM (program), and
RANDOM indicators
r Radio frequency indicators
• kHz and MHz indicators
a 7 (stop) button (14 – 25, 27)
s TUNING + and – buttons (12)
1 and ¡ (fast left/fast right) buttons (14, 23)
d MIC LEVEL control (26 – 27)
f MIC jack (26)
g Video CD buttons
• PBC button (18 – 19)
•
RETURN button (18)
• VCD NUMBER + / –buttons (18)
h DISC 3¥8 SELECT (play/pause) button (10, 14 – 19, 21)
Pressing this button also turns on the unit.
j FM/AM button (12)
Pressing this button also turns on the unit.
k TAPE-B 2 3 button (10, 23 – 24)
Pressing this button also turns on the unit.
l Deck B cassette holder (23 – 24)
/ EJECT 0 button for deck B (23 – 24)
S.MODE
ACTIVE
BASS EX.
SLEEP
MP3 MONO
ST
PBC
RANDOM
ALL
CD
1
PRGMREPEAT
DAILY REC
SOUND
TURBO
1 2 3
REC
A
B
kHz MHz
RDS TA
NEWSINFO
