JVC CA-MXSK1 Stereo System User Manual



– 33 –
English
Specifications
CA-MXSK3
Amplifier section
Output Power
MAIN SPEAKERS: 80 W per channel, min. RMS, both
channels driven into 6 at 1 kHz with no
more than 0.9% total harmonic distortion.
SURROUND SPEAKER: 20 W per channel, min. RMS, both
channels driven into 16 at 1 kHz with
no more than 0.9% total harmonic
distortion.
Audio input sensitivity/Impedance
(Measured at 1 kHz, with tape recording signal 300 mV)
AUX: 400 mV/50 k
MIC: 3 mV/10 k
Tuner
FM tuning range: 87.50 MHz – 108.00 MHz
AM tuning range:
For Saudi Arabia:
At 9 kHz intervals: 531 kHz – 1 602 kHz
At 10 kHz intervals: 530 kHz – 1 600 kHz
For other countries:
At 9 kHz intervals: 531 kHz – 1 710 kHz
At 10 kHz intervals: 530 kHz – 1 710 kHz
CD player
CD capacity: 3 CDs
Dynamic range: 85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz — 14 000 Hz
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 110 V / AC 127 V / AC 220 V /
AC 230 V – AC 240 V
(adjustable with the voltage selector),
50 Hz / 60 Hz
Power consumption: 110 W (at operation)
20 W (on standby)
Dimensions (approx.): 270 mm x 306 mm x 433.5 mm (W/H/D)
Mass (approx.): 9.3 kg
Supplied accessories
See page 6.
Design and specifications are subject
to change without notice.
Speaker Specifications: SP-XSK3 (Main Speaker)
Type: 3-Way 3 Speaker Bass-Reflex
(Magnetically-Shielded Type)
Speakers
Main woofer : 15cm cone x 1
Mid Range : 5.0cm cone x 1
Tweeter : 2.0cm dome x 1
Power Handling Capacity
Main Speaker : 100 W
Impedance
Main Speaker : 6
Frequency Range
Main Speaker : 42 Hz – 30 000Hz
Sound Pressure Level
Main Speaker : 84 dB/W.m
Dimensions (W x H xD)
Main Speaker : 215mm x 306 mm x 243 mm
Mass
Main Speaker : 3.4 kg
Design and specifications subject to change without notice.
Speaker Specifications: SP-XSSK3 (Surround Speaker)
Type: Full range bass-reflex type
Speakers
Full range : 8cm cone x 1
Power Handling Capacity : 30 W
Impedance : 16
Frequency Range : 85 Hz – 20 000Hz
Sound Pressure Level : 83 dB/W.m
Dimensions (W x H xD) : 160mm x 110 mm x 136 mm
Mass : 0.55 kg
Design and specifications subject to change without notice.
