– 20 –
English
The TV screen will show the following:
3
Press the number button for
the video intro you want to
select.
Playback starts from the selected
track.
To stop and cancel the video intro
play, press 7.
Viewing the Highlights of a Video CD
You can view highlight scenes of the selected track on a
video CD only when PBC is off. These highlight scenes are
created by dividing the track equally into 9 portions and the
beginning scenes (about 7 seconds each) of those 9 portions
are shown on the display.
1
Press DISC 1-3, and the number
button for the track you want to
view the highlights of.
Playback starts.
2
Press HIGHLIGHT on the remote
control after a picture appears on the
TV screen.
The highlight play starts and shows in sequence, the first
7 seconds of nine track divisions on the TV screen. To
preview subsequent tracks, press
¢ (NEXT ¡)
on the
remote control.
TV screen will show the following:
3
Press the number button for
the highlight you want to
select.
Playback starts from the selected
scene.
To stop and cancel the highlight play,
press 7.
Viewing highlights
When a highlight scene is selected, playback starts from the
beginning of the highlight scene, but not from the still image
shown on the display (the part shown is the last part of the
highlight scene, not its beginning).
During the video intro or highlight play, images shown on the
display may be partially distorted, resulting from noise or
incorrect manufacturing of the disc.
Highlight also can function in stop position.
When STILL/PAUSE function is on, HIGHLIGHT and VIDEO
INTRO functions are not available.
Playing a Multiplex Sound CD
This function is used for multiplex sound discs. See manuals
attached to discs for detailed information.
Operation
By pressing the MPX button on the remote control
consecutively, channel multiplexing modes are
cycled as shown below.
When MONO L or MONO R is selected, display indicates
MONO L or MONO R respectively.
MONO L: Only the left channel is played back through
both right and left speakers.
MONO R: Only the right channel is played back
through both right and left speakers.
STEREO: Used for conventional stereo sources.
MONO LSTEREO
MONO R
(Left channel/
Right channel)
08/10 00:07
DISC 2
12 3
45 6
78 9
VIDEO INTRO ¢
HIGHLIGHT
08/10 00:07
DISC 2
12 3
45 6
78 9
4 HIGHLIGHT ¢
MPX /
FM MODE
