DCP Rear Panel Source Unit Front
Source unit connector
DCP
connector
5. DCP
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the included DCP case to prevent scratches.
We recommend taking the control panel with you
when leaving the car.
Removing the DCP
1. Hold down POWER button 3 for 1 second or
longer to turn off the power.
2. Press the DCP Release button 1.
∗ The DCP is unlocked
3. Remove the DCP.
Attaching the DCP
Insert the DCP into the right side of the source
unit and press the left side to lock it.
Do not insert the DCP from the left side. Do-
ing so may damage it.
Storing the DCP in the DCP Case
Hold the DCP, in the orientation as shown in the
figure below, and put it into the supplied DCP
case. (Ensure the DCP is in the correct orienta-
tion.)
• The DCP can easily be damaged by shocks.
After removing it, place it in a protective
case and be careful not to drop it or subject
it to strong shocks.
• When the Release button is pressed and the
DCP is unlocked, the car’s vibrations may
cause it to fall. To prevent damage to the
DCP, always store it in its case after detach-
ing it.
• The rear connector connecting the main unit
and the DCP is an extremely important part.
Be careful not to damage it by pressing on
it with fingernails, pens, screwdrivers, etc.
Note:
•
If the DCP is dirty, wipe off the dirt with a soft, dry
clothonly.
