Clarion RMX465D CD Player User Manual



RMX465D 4RMX465D 356 RMX465D
2. PRECAUTIONS
1. When the inside of the car is very cold and
the player is used soon after switching on
the heater moisture may form on the disc or
the optical parts of the player and proper
playback may not be possible. If moisture
forms on the disc, wipe it off with a soft cloth.
If moisture forms on the optical parts of the
player, do not use the player for about one
hour. The condensation will disappear natu-
rally allowing normal operation.
This equipment has been tested and found to
comply with the limits for a Class B digital de-
vice, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference in
a residential installation.
This equipment generates, uses, and can radi-
ate radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio com-
munications. However, there is no guarantee
that interference will not occur in a particular
installation.
If this equipment does cause harmful interfer-
ence to radio or television reception, which can
be determined by turning the equipment off and
on, the user is encouraged to consult the dealer
or an experienced radio technician for help.
2. Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
3. This unit uses a precision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.
CAUTION
USE OF CONTROLS, ADJUSTMENTS, OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY RE-
SULT IN HAZARDOUS RADIATION EXPO-
SURE.
THE COMPACT DISC PLAYER and MINI DISC
PLAYER SHOULD NOT BE ADJUSTED OR
REPAIRED BY ANYONE EXCEPT PROPERLY
QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT EX-
PRESSLY APPROVED BY THE MANUFAC-
TURER FOR COMPLIANCE COULD VOID
THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
INFORMATION FOR USERS:.
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE MANU-
FACTURER WILL VOID THE WARRANTY
AND WILL VIOLATE FCC APPROVAL.
Handling MD
Storage
• Do not expose minidiscs to direct sunlignt or
any heat source.
Do not expose minidiscs to excess humidity or
dust.
Do not expose minidiscs to direct heat from
heaters.
Cleaning
If the MD cartridge is dirty, wipe off the dirt
with a soft dry cloth.
• Discs recorded in monaural mode cannot be
played on this unit.
Be sure to unfold and read the next page.
Veuillez déplier et vous référer à la page suivante.
Cerciórese de desplegar y de leer la página siguiente.
Bottom View of Source Unit
12V GROUND
MODEL
SERIAL No.
PE-
286-
Clarion Co.,Ltd.
MADE IN
AM 530-1710kHz/FM 87.9-107.9MHz
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES.OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERA-
TION.
THIS PRODUCTION COMPLIES DHHS RULES 21 CFR
SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.
US AND FOREIGN PATENTS LICENSED FROM DOLBY
LABORATORIES LICENSING CORPORATION
CLARION CO.,LTD.
50 KAMITODA,TODA-SHI,SAITAMA-KEN,JAPAN
MANUFACTURED:
11. ESPECIFICACIONES
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
11 dBf
Sensibilidad a 50 dB de silenciamiento:
17 dBf
Selectividad de canal alternativo:
75 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25
µ
V
Reproductor de minidiscos
Respuesta en frecuencia (±2 dB):
20 Hz a 20 kHz
Relación señal-ruido (1 kHz):
90 dB
Gama dinámica (1 kHz):
85 dB
Distorsión armónica:
0,01%
Audio
Salida máxima de potencia:
180 W (45 W × 4 canales) (EIAJ)
Salida media continua de potencia:
16 W × 4, con 4 , de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves (30 Hz):
±13 dB
Acción de control de agudos (10 kHz):
±10 dB
Salida de línea (reproductor de minidiscos 1 kHz):
1,8 V
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A
Impedancia de los altavoces:
4 (permisible de 4 a 8 )
Peso / Unidad fuente:
3,3 lb. (1,5 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7
"
(An) × 2
"
(Al) × 6-1/8
"
(Prf)
[178 (An) × 50 (Al) × 155 (Prf) mm]
Dimensiones / Controlador remoto:
1-3/4
"
(An) × 4-5/16
"
(Al) × 1-1/8
"
(Prf)
[44 (An) × 110 (Al) × 27 (Prf) mm]
Notas:
Las especificaciones están de acuerdo con las normas de la EIA.
Licencia de patentes en EE.UU y otros países por parte de Dolby Laboratories Licensing Corporation.
Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.
Cartridge
Shutter
Use only MDs bearing the mark.
Handling
Never open the shutter on the MD cartridge.
Never play a minidisc with an index label that
is peeling off .
If you try to play such a minidisc, you may not
be able to get it back out of the MD player or it
may damage the MD player.
