RMX465D 19
11. SPECIFICATIONS
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
11 dBf
50dB Quieting Sensitivity:
17 dBf
Alternate Channel Selectivity:
75 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25
µ
V
MD Player
Frequency Response (±2 dB):
20 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
90 dB
Dynamic Range (1 kHz):
85 dB
Harmonic Distortion:
0.01%
Notes:
• Specifications comply with EIA Standards.
• U.S. and foreign patents licensed from Dolby Laboratories Licensing Corporation.
• Specifications and design are subject to change without notice for further improvement.
Audio
Maximum Power Output:
180 W (45 W × 4 ch) (EIAJ)
Continuous Average Power Output:
16 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (30 Hz):
±13 dB
Treble Control Action (10 kHz):
±10 dB
Line Output Level (MD 1 kHz):
1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Current Consumption:
Less than 15 A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
3.3 lb. (1.5 kg)
Weight / Remote control unit:
1 oz. (30 g) (including battery)
Dimensions / Source unit:
7
"
(Width) × 2
"
(Height) × 6
-
1/8
"
(Depth)
[178 (W) × 50 (H) × 155 (D) mm]
Dimensions / Remote control unit:
1-3/4
"
(Width) × 4-5/16
"
(Height) × 1
-
1/8
"
(Depth)
[44 (W) × 110 (H) × 27 (D) mm]
