12 DXZ935
English
6. DCP
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the car.
Removing the DCP
1. With the DUAL ACTION closed, turn off the
power.
2. Press the [RELEASE] button deeply and
take and pull the DCP to detach the DCP.
2. Press the left side C of the DCP carefully to
fit it in place.
CAUTION
Attaching the DCP
1. Insert the DCP so that the A section on the
right side of the DCP catches on the hook B
on the unit.
• Always close the DUAL ACTION before remov-
ing the DCP.
• If you remove the DCP with the DUAL ACTION
open, the sloping console closes immediately.
Be careful not to get your fingers caught.
• The DCP can easily be damaged by shocks.
After removing it, be careful not to drop it or
subject it to strong shocks.
• If the [RELEASE] button is pressed and the
DCP is not locked into place, it may fall out
from vibration of the car. This can break the
DCP, so after removing it, either install it on
the unit or put it in its DCP case.
• The connector connecting the unit and the
DCP is an extremely important part. Be careful
not to damage it by pressing on it with finger-
nails, screwdrivers, etc.
• If you apply to the control panel more force
than that required with the control panel left
open, the control panel will go down one step.
This is due to safety mechanism engaged and
is not a malfunction. In this case, press the [O]
button two times to return the control panel to
the original operating position. Using the con-
trol panel being lowered results in a damage
to the panel.
• Do not use the control panel being left open
as a tray to put an object on.
•
Moving the control panel manually will cause a
malfunction such as getting out of order of the
sloping mechanism, breakdown of the gears,
etc. Do not draw the control panel forcibly.
When the control panel is moved manually,
press the [O] button several times to see if the
control panel returns to the normal position
and functions properly.
• Do not remove the DCP while you are driving
a car.
• Do not use the DCP being rickety.
• Do not carry the DCP in a trouser pocket or
the like directly. (The DCP may be damaged
under load conditions.)
• The DCP may jump out of the DCP case hous-
ing the DCP when the case is opened ener-
getically.
Note:
• If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
