4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
[RELEASE] button
• Deeply press the button to remove the DCP.
[VSE] button
• Press to enter VSE mode or the Position
mode.
•
When the button is pressed and hold for 1 sec-
ond or longer, the mode is turned on or off.
[EQ] button
• Press to enter the EQ mode.
•
When the button is pressed and hold for 1 sec-
ond or longer, the mode is turned on or off.
[FNC] button
• Press the button to turn on the power.
Press and hold the button for 1second or
longer to turn off the power.
• Switches the operation mode among the ra-
dio mode, etc.
[SAT] button
• This button is available only when the unit is
connected with Satellite Digital Radio Tuner
(sold separately DSH920S).
[ ] button
• Plays or pauses a CD while in the CD mode.
• Used as “Enter button” while the unit is in the
ADJ mode.
[O] button
• Use the button to open the dual action.
[DISP] button
• Switches the display indication (Main display,
clock display).
[A-M] button
• Use the button to switch to the audio mode
(balance/fader/sub.w/center SP/NF. adjust-
ment)
[RD] button
• Performs random play while in the CD mode.
[ISR] button
• Recalls ISR radio station in memory.
• Press and hold for 2 seconds or longer:
Stores current station into ISR memory (radio
mode only).
Names of the Buttons and their Functions
●When the CD/MD/DVD changer
is connected
∗ For details, see the section “CD/MD/DVD
changer operations”. For the DVD
changer, refer to the Owner’s Manual pro-
vided with the DVD changer.
[SC] button
• Performs scan play for 10 seconds for each
track. Disc scan play is performed when the
button is pressed and held.
[RP] button
•
Performs repeat play. When this button is
pressed and held, disc repeat play is performed.
[RD] button
• Performs random play. Also performs disc ran-
dom play when the button is pressed and
held.
[DIRECT] button
• Designates the disc to be played.
[DISP] button
• Switches the clock or selects the title mode.
• When the button is pressed and held, the user
titles or disc titles are switched.
[TITLE] button
• Use the button to input a title in the CD
changer mode.
•
Use the button to scroll the title during CD-text
play or MD changer play in the CD changer mode.
[ ] button
• Plays or pauses a CD, MD or DVD.
[a], [d] buttons
•
Selects a track when listening to a disc.
[BND] button
• Plays a first track.
• Used as “disc up button” while the unit is in
the DVD changer mode.
●When the TV/DAB is connected
∗ For details, see the section “TV opera-
tions” or “DAB operations”.
[SC] button
• Used to perform preset or category scan
while the unit is in the radio mode. When the
button is pressed and held, auto store is
performed.(This function is available only in
the TV tuner mode.)
[RP] button
•
Press the button to turn on or off the AF (Alter-
native Frequency) function in the DAB mode.
(This function is only DAB tuner.)
[RD] button
•
Use the button to set the PTY (Programme Type)
standby mode or PTY items in the DAB mode.
• Switches the TV picture mode or VTR (external)
picture mode.
[DIRECT] button
•
Stores a station into memory or recall it directly.
[a], [d] buttons
• Selects a station.
[BND] button
• Switches the band.
• When the button is pressed and held,
switches seek tuning or manual mode.
●When the DTS/DOLBY DIGITAL
is connected
[VSE] button
• Press the button to turn on the DSF.
• After DSF is selected, press and hold the
[VSE] button for 1 second or longer to turn to
off DSF effect.
[PLII ] button
• Press the button to turn on the PLII, and each
time to press PLII mode changes following or-
der:
Music mode ➜ Matrix mode ➜ Movie mode
➜ Virtual mode ➜ mode off
Major button operations when external equipment is
connected to this unit
[RP] button
• Plays repeatedly while in the CD mode.
[SC] button
• Performs preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
• Performs scan play for 10 seconds for each
track while in the CD mode.
[BND] button
• Switches the band, or seek tuning or manual
tuning while in the radio mode.
• Plays a first track while in the CD mode.
[TITLE] button
• Use the button to input a title in the CD mode
and radio mode.
• Press and hold the button for 1 second or
longer to enter the adjust mode.
[a], [d] buttons
• Selects a station while in the radio mode or
selects a track when listening to a CD. These
buttons are used to make various settings.
[ROTARY] knob
• Adjust the volume by turning the knob clock-
wise or counterclockwise.
• Use the knob to perform various settings.
[PLII] button
• Press to select the Dolby Pro Logic II mode.
[DIRECT] button
• Stores a station into memory or recall it di-
rectly while in the radio mode.
[CD SLOT]
• CD insertion slot.
[CD EJECT] button
• Press to eject a CD loaded in the unit.
• Press to open the CD slot and insert a CD.
[RESET] button
• Press to reset the system.
3. CONTROLS / LES COMMANDES / CONTROLES
Source unit / Appareil pilote / Unidad fuente
With the Dual Action opened / Lorsque la Double action est ouverte
Con el panel frontal de acción doble abierto
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
[
RELEASE
]
[
VSE
]
[
EQ
]
[
FNC
]
[
SAT
]
[
O
]
[
DISP
]
[
RD
]
[
A-M
]
[
BND
][
RP
][
TITLE
]
[
ISR
]
[
PLII
]
[
SC
]
[
DIRECT
]
[
ROTARY
]
[
CD EJECT
]
[
RESET
]
[
CD SLOT
]
