Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer, DVD changer, AUX,
DAB, DSP DVD, PHONE MUTE and TV tuner connected via the CeNET cable. The CD changer, MD
changer, DVD changer and TV tuner have their own manuals, but no explanations for operating them
are described.
2 DXZ935
Contents
1. FEATURES ...................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Dual Action ...................................................................................................................................... 3
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS..................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major button operations when external equipment is connected to this unit ................................... 7
Display Items ................................................................................................................................... 9
LCD Screen ..................................................................................................................................... 9
5. REMOTE CONTROL..................................................................................................................... 10
Names of Parts .............................................................................................................................. 10
Functions of Remote Control Unit Buttons .................................................................................... 10
Loading Battery ............................................................................................................................. 10
Attaching the Remote Control Unit to the Steering Wheel .............................................................11
6. DCP ............................................................................................................................................... 12
7. OPERATIONS ............................................................................................................................... 13
Basic Operations ........................................................................................................................... 13
AC-Processor II Operations ........................................................................................................... 15
Radio Operations ........................................................................................................................... 18
CD Operations ............................................................................................................................... 20
Operations Common to Each Mode .............................................................................................. 21
8. OPERATIONS OF ACCESSORIES .............................................................................................. 24
CD/MD/DVD Changer Operations ................................................................................................. 24
TV Operations ............................................................................................................................... 26
Digital Radio/DAB Operations ....................................................................................................... 27
DVD DECK Operations ................................................................................................................. 31
9. IN CASE OF DIFFICULTY ............................................................................................................ 32
10. ERROR DISPLAYS ....................................................................................................................... 33
11. SPECIFICATIONS ....................................................................................................................... 103
1. FEATURES
• Dual Action Detachable Alminum Face
• Rotary Encorder volume Control
• Controller for Optional DAB, SIRIUS, TV Tuner
CD, MD, DVD Changer, DVD Deck, B.B.DTS
• Capability to Read CD TEXT Data, CD-R,CD-
RW
• CeNET with Balanced Audio Line Transmission
and Dynamic Noise Cancelling
•
®
FM Reception System
• AC-Processor II including Dolby Pro Logic II
for user like sound making
• 4V/4-Channel RCA LineLevel Output with
Fader Control
• 2-Channel RCA AUX Input
• 212 W (53 W × 4) Maximum Power Output
DXZ935 105
English
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
9 dBf
Sensibilidad a 50 dB de silenciamiento:
15 dBf
Selectividad de canal alternativo:
70 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25 µV
Reproductor de discos compactos
Sistema:
Sistema audiodigital de discos compactos
Discos utilizables:
Discos compactos
Respuesta en frecuencia (±1 dB):
5 Hz a 20 kHz
Relación señal-ruido (1 kHz):
100 dB
Gama dinámica (1 kHz):
96 dB
Distorsión armónica:
0,01%
Audio
Salida máxima de potencia:
212 W (53 W ✕ 4 canales)
Salida media continua de potencia:
18 W ✕ 4, con 4 Ω, de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves (50 Hz):
±12dB
Acción de control de agudos (12,5 kHz):
±12 dB
Salida de línea (reproductor de discos compactos 1 kHz):
4 V/F 2ch + 4 V/R 2ch
4 V/NON-FADER 2ch
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A
Impedancia de los altavoces:
4 Ω (permisible de 4 a 8 Ω)
Peso / Unidad fuente:
3,75 lb. (1,7 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7" (An) ✕ 2" (Al) ✕ 6-1/8" (Prf)
[178 (An) ✕ 50 (Al) ✕ 155 (Prf) mm]
Dimensiones / Controlador remoto:
1-1/4" (An) ✕ 2-3/16" (Al) ✕ 15/16" (Prf)
[32 (An) ✕ 56 (Al) ✕ 24 (Prf) mm]
11. ESPECIFICACIONES
Notas:
• Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.
