DXZ935 27
English
1. Press the [BND] button and select the de-
sired TV band (TV1 or TV2).
2. Press and hold the [SC] button for 2 seconds
or longer. The stations with good reception
are stored automatically to the preset chan-
nels.
Preset scan
Preset scan allows the user to view each preset
position before it automatically advances to the
next preset. This function is useful for searching
for a desired TV station in memory.
1. Press the [SC] button.
2. When the desired station is found, press the
[SC] button again to remain tuned to that sta-
tion.
Note:
• Do not press and hold the [SC] button for 2 sec-
onds or longer. Doing so will trigger the auto store
function and start storing stations into memory.
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
1.
Press and hold the [TITLE] button for 1 second or
longer to switch to the adjustment selection display.
2. Press the [a] or [d] button to select “TV
DIVER”.
3. Turn the [ROTARY] knob clockwise to set to
“ON” or counterclockwise to set to “OFF”.
● “DIVER ON”
Sets reception emphasizing the visual.
● “DIVER OFF”
Sets the diver setting to OFF.
4. Press the [TITLE] button to return to the pre-
vious mode.
TV Operations
Digital Radio / DAB Operations
DAB control function
When a CeNET cable is used to connect a DAB
(DAH913) (sold separetely), all functions can be
operated.
Listening to the DAB station
1. Press the [FNC] button to select the DAB
mode.
2. When the unit receives a DAB station, the
display changes in the following order:
Frequency channel ➜ service label
Switching displays
Press the [DISP] button for 1 second during the
Main (service label) display to select Main (ser-
vice label) or Sub (PTY).
Notes:
• The display shown in the normal reception mode
and the preset reception mode is the same when
a DAB station is received.
• The number of programmes and broadcasting
times depend on the DAB stations.
• When the strength of DAB signals is weak, audio
output is muted.
Seek tuning
1.
Press the [FNC] button to select the DAB mode.
2. Press and hold the [a] or [d] button for 1
second or longer.
∗ “SEARCHING” appears in the display.
3. “DAB” lights up in the display when the main
unit receives a DAB station.
* The main unit stops the seek tuning when it
cannot find a DAB station. The display returns
to the previous mode.
Manual tuning
1.
Press the [FNC] button to the select the DAB
mode.
2. Press and hold the [BND] button for 1 second
or longer. “MANU” lights up in the display.
3. Press the [a] or [d] button to select a sta-
tion.
∗ If no operation is performed for more than 7
seconds, manual tuning is cancelled and the
display returns to the previous mode.
