GSM Section
The GSM section configures the GSM/GPRS radio. If there is no GSM radio installed in the
mobile device, disable this section.
Key Description Available Value
Enable Enables and disables the GSM radio.
Default value: 0
0=Disable 1=Enable; when enabled, the
802.11b radio turns off automatically.
APN Enter the Access Point Name (APN) for
the GPRS network.
Default value: Empty
APN value
IPAddress Enter the IP Address.
Default value: Empty
Empty=GSM uses DHCP (server-
assigned IP address) X=IP address
Protocol Enter the protocol to use.
Default value: IP
Protocol type
ActiveSync Section
The ActiveSync Section configures the mobile devices ActiveSync connection parameters.
Key Description Available Values
AutoConnect Enables and disables the
ActiveSync connection when the
mobile device first connects to the
communication peripheral.
Default value: 1
0=Disable ActiveSync connection
1=Enable ActiveSync connection
Connection Specifies the connection type and
baud rate.
Default value: ‘USB Connection
`USB Connection
`115200 Default
`19200 Default
`38400 Default
`57600 Default
Note: These values must be typed in
exactly as they appear here.
