NAS-C5E 3-280-821-12(1)
DSGX button
Use to generate a more dynamic sound (page
30). Each press of the button switches the
DSGX (Dynamic Sound Generator X-tra)
function “On” or “Off”. This function is
factory set to “On”.
VOLUME +* and VOLUME – buttons
Use to adjust the volume.
Menu operation buttons
Use to select menu items and enter menu
settings (page 11).
, , and buttons
Use to select a menu item or to change a
setting.
ENTER button
Use to enter a setting.
PARTY button
Use to enter or leave PARTY MODE (page
22).
Music Surfin’ buttons
Use to select the additional channels of
Music Surfin’ during x-DJ (page 26).
(power) button
Turns the power on or off.
AUDIO IN button
Selects the Audio In function and plays
audio data on an external device connected
to the AUDIO IN jack of the unit. Sound is
output from the unit’s speakers (page 29).
button
Use to start or pause playback.
PRESET EQ button
Selects a pre-set customized sound setting
(page 30). Each press of the button changes
the sound style as follows.
FLAT ROCK POPS JAZZ
CLASSICAL DANCE FLAT ...
(
: Factory setting)
x-DJ button
Selects and plays an x-DJ channel on the
“GIGA JUKE” Music Server (page 24).
To insert the batteries into the remote
control
Slide and remove the battery compartment lid,
and then insert the two supplied R6 (size AA)
batteries ( end first) matching the polarities as
shown below.
When the remote control is no longer able to
operate the unit, replace both batteries with new
ones.
Note
Be sure to keep the remote sensor of this unit out of
direct sunlight or bright lights, or the remote control
may stop working.
