Optional Components
47
Connecting a VCR
Make sure to match the color of the plugs and the
connectors. To listen to the sound of the connected
VCR, press ?/1 while holding down FUNCTION
when the power is turned off. This switches “MD”
to “VIDEO.” Once you enable the “VIDEO”
function, just press FUNCTION repeatedly until
“VIDEO” appears.
To the audio output of the VCR
Note
If the sound is distorted when selecting “VIDEO,” or
you want to switch back to “MD,” repeat the
operation described above.
Connecting external
antennas
Connect the external antenna to improve the
reception.
FM antenna
Connect the optional FM external antenna. You
can also use the TV antenna instead.
FM75
AM
75-ohm coaxial
cable
(not supplied)
AM antenna
Connect a 6- to 15- meter (20- to 50- foot)
insulated wire to the AM antenna terminal.
Leave the supplied AM loop antenna connected.
Insulated wire (not supplied)
FM75
AM
