28
GB
To enjoy TV or VCR sound from all the speakers without a
SCART jack
Connect the AUDIO OUT (L/R) jacks (1) to the VIDEO or SAT AUDIO IN (L/R) jacks of this
subwoofer with audio cords (not supplied). If your TV does not have the AUDIO OUT (L/R) jacks,
you cannot output the TV sound from the speakers of this subwoofer. If your TV has an OPTICAL
DIGITAL OUT jack (2), connect to the SAT OPTICAL DIGITAL IN jack of this subwoofer using
an optical digital cord (not supplied).
Tip
Select either VIDEO or SAT, according to the TV connection, by pressing FUNCTION repeatedly (page 67).
When you want to output the TV sound or stereo sound of a 2 channel source from the 6 speakers, select
any sound field other than “Auto Format Direct Auto” or “2Channel Stereo” (page 63).
To enjoy TV sound from all speakers
R
AUDIO
OUT
L
VIDEO
OUT
R
AUDIO
OUT
L
VIDEO
OUT
OPTICAL
DIGITAL
OUT
IN
VIDEO
PHONES
REMOTE
CONTROL
OPTICAL
DIGITAL IN
IN
VIDEO DIR-T1
FM
75
COAXIAL
AM
IN
LL
AUDIO
R
R
IN
AUDIO
FRONT R
CENTER FRONT L
ANTENNA
IMPEDANCE USE 4
SPEAKER
SAT
SYSYTEM CONNECTOR
VIDEO
EURO AV
OUTPUT(TO TV)
or
Digital satellite receiver,
PlayStation 2, etc.
TV, VCR, etc.
1
1
2
