10
To the audio
input/output of
the MD deck
Connecting optional
AV components
To enhance your system, you can connect
optional components. Refer to the
instructions included with each component
for details.
Connecting audio
components
Connecting an MD deck for analog
recording
Be sure to match the colour of the plugs and
the connectors. To listen to the sound from
the connected MD deck, press FUNCTION
repeatedly until “MD” appears.
Connecting a VCR
Be sure to match the colour of the plugs and
the connectors. To listen to the sound from
the connected VCR, press FUNCTION
repeatedly until “MD” appears.
Connecting an MD deck for digital
recording
You can record from CD into the MD deck
digitally by connecting an optical cable.
To the digital
input of the
MD deck
To the audio
output of the
VCR
