35
Operation
Making a Recording
Making an Audio or a Video Recording
The following steps show you how to make an audio or a video recording from the built in tuner, or from an
audio or video source connected to the receiver (such as a CD player or TV). Recordings can be made to a CD-
Recorder, cassette deck, MD, VCR, or DVR deck connected to the CD-R/TAPE/MD, VCR or DVR in/out
connectors.
The receiver's volume, balance tone (bass, treble, loudness), and surround effects (Dolby
Pro Logic/Dolby Digital and DSP settings) have no effect on the recorded signal.
MONITOR
1
Record MONITOR
You can listen to (monitor) the recording as it's being made using the
MONITOR button on the the front panel if your recording components
are connected to the CD-R/TAPE/MD input (a cassette deck would have
to have a record monitor function).
Press the MONITOR button to switch between the recorded signal and
the original source signal.
1
Press the MULTI CONTROL button on the
remote control of the source component .
Make sure the DIRECT FUNCTION is ON (see p, 22).
All functions except MONITOR are accessible from the remote
control.
On the receiver, select the source directly using the front panel
buttons.
2
Prepare the program source.
Tune to the radio station, load the CD, etc. For a video recording
load the video, DVD etc.
3
Insert a blank tape, MD, video etc. into the
recording device connected to either CD-R/
TAPE/MD or VCR/DVR and set the recording
levels.
Refer to the instructions that came with the recorder if you are
unsure how to do this.Most video recorders set the audio recording
level automatically—check your video's instruction manual if you
are unsure whether yours has manual controls.
4
Start recording, then start playback of the
source component.
memo
MULTI CONTROL
DVD/LD TV/SAT VCR/DVR CD
LOUDNESS FUNCTION MUTING
RECEIVER
D.ACCESS CHANNEL
ATT
VOL
MENU
TOP
MENU
VOL
CH
2
DSP MODE
MIDNIGHT
5.1CH
CD-R/
TAPE/MD
CHANNEL
SELECT
CHANNEL
LEVEL
EFFECT
ENTER
ENTER
FQ
FQ
ST ST
FL
DIMMER
REMOTE
SETUP
MASTER
VOLUME
AUDIO/VIDEO PRE-PROGRAMMED
REMOTE CONTROL UNIT
TV CONTROL
FUNC
10 DISC
SIGNAL
SELECT
TEST
TONE
RECEIVER
TUNER
TV CONT
Î
1234
1 ¡ 4 ¢
7 8 3
5678
90
‡
SOURCE CLASS MPX BAND
1
