Panasonic RX-ED50 Speaker System User Manual



RQT5142
7
Before use
The remote control
Buttons
Number Designation Reference Page
Sound virtualizer button (S.VIRTUALIZER) . . . . 22
CD skip/search buttons ( , ) . . . . . . . . . . . .11
Tuning buttons (–TUNE+)
Rewind/fast forward TPS buttons (REW
FF)
Tape counter reset button (C-RESET) . . . . . . . . 16
Reverse mode select button
(REV MODE) . . . . . . . . . . . . . . . . . . . . . . . . . . 15–16
Numbered buttons . . . . . . . . . . . . . . . . . . . 10–11,13
Sleep timer button (SLEEP) . . . . . . . . . . . . . . . . . 21
Program memory button
(PROGRAM MEMORY) . . . . . . . . . . . . . . . . . . . 11,13
Timer fader button (TIMER FADER) . . . . . . . . . . 22
Tape stop/mode select button ( ) . . . . . . . . . . . 15
FM mode BP button (FM MODE/BP) . . . . . . . . 12,19
CD stop/program clear/mode select button
( /CLEAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–11
CD play mode button (PLAY MODE) . . . . . . . . . . 10
Display select button (DISPLAY) . . . . . . . . . . . 8,16
When the unit is supplied with AC power, buttons to
,
,
, and
function in the same way as the controls
on the main unit. To save power, the unit cannot be turned
on from the remote control when batteries are used.
Batteries (not included)
Insert so the poles (+ and –) match those in the remote control.
Remove if the remote control is not going to be used for a
long period of time. Store in a cool, dark place.
Replace if the unit does not respond to the remote control
even when held close to the front panel.
Use
Aim at the sensor, avoiding obstacles, at a maximum range
of 7 meters directly in front of the unit.
Keep the transmission window and the unit’s sensor free
from dust.
Operation can be affected by strong light sources, such
as direct sunlight, and the glass doors on cabinets.
Do not;
put heavy objects on the remote control.
take the remote control apart.
spill liquids onto the remote control.
PORTABLE STEREO CD SYSTEM
PORTABLE STEREO CD SYSTEMPORTABLE STEREO CD SYSTEM
30˚30˚
(R6,AA,UM3)
SENSOR
7m
