– 23 –
Symptom
No sound is heard.
Power cannot be turned on.
The disc does not play.
The disc sound is discontinuous.
No picture is displayed on TV screen.
No color is shown on TV screen.
Hard to listen to broadcasts because of
noise.
Tape playback sound is at a very low level.
Impossible to record on a tape.
Timer operation does not start.
Unable to operate the unit with the remote
control.
The MP3-CD does not play.
Cause
Connections are incorrect or loose.
The power cord is unplugged.
• The disc is placed upside down.
• The moisture has been condensed on the
lens.
• The disc format is not supported on the
unit.
The disc is scratched or dirty.
The unit is not connected to the TV set or
the connection is loose.
The unit is not switched to the PAL or
NTSC setting corresponding to the TV set.
Antenna orientation is not correct.
The heads are dirty.
Small tabs on the back of the cassette are
removed.
The current time is not set correctly.
• The path between the remote control and
the remote sensor on the unit is blocked.
• The batteries are exhausted.
The disc is not finalized.
Action
Check all connections and make
corrections. (See pages 6, 7.)
Connect the power cord.
• Place the disc with the label side up.
• Wait until the moisture condensation at
the lens has cleared.
• Use a disc recorded in the correct format.
Clean or replace the disc. (See page 22.)
Connect the cable between the unit and TV
set correctly.
Change the PAL/NTSC setting of the unit.
Readjust the antenna. (See page 7.)
Clean the heads. (See page 22.)
Cover the holes with adhesive tape.
Set the built-in clock correctly.
• Remove the obstruction.
• Replace the batteries.
Use a finalized MP3-CD.
Troubleshooting
If you are having a problem with your unit, check this list for a possible solution before calling for service.
If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person,
such as your dealer, for service.
Specifications
Amplifier
Output Power
32 W (16 W + 16 W) at 8 Ω (MAX.)
24 W (12 W + 12 W) at 8 Ω (10 % THD)
Audio input sensitivity/Impedance (at 1 kHz)
MIC: 5 mV/48 kΩ
Speakers/Impedance 8 Ω - 16 Ω
Tuner
FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range
At 9kHz intervals: 531 kHz - 1 602 kHz
At 10kHz intervals: 530 kHz - 1 710 kHz
CD player
Dynamic range 60 dB
Signal-to-noise ratio 60 dB
Wow and flutter Unmeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz - 14 000 Hz
Wow and flutter 0.4 % (WRMS)
General
Power requirement
AC 110 V - 127 V/220 V - 240 V Ó adjustable with the
voltage selector, 50 Hz/60 Hz
Power consumption 35 W (operation mode)
4.5 W (standby mode)
Dimensions Approx.
160 mm × 269.5 mm × 300 mm
(W/H/D)
Mass Approx. 5 kg
Speaker
Speaker unit Woofer: 10.2 cm cone × 1
Tweeter: 5.1 cm cone × 1
Impedance 8 Ω
Dimensions Approx.
160 mm × 269.5 mm × 192 mm
(W/H/D)
Mass Approx. 2 kg/each
Supplied Accessories
See page 6.
Design and specifications are subject to change without
notice.
