Clarion WXZ466MP CD Player User Manual



280-8171-00
WXZ466MP 29
English
FM Tuner
Frequency Range:
87.0 MHz to 108.0 MHz
Usable Sensitivity:
9 dBf
50dB Quieting Sensitivity:
15 dBf
Alternate Channel Selectivity:
70 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
531 kHz to 1629 kHz
Usable Sensitivity:
25 µV
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (±1 dB):
10 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
90 dB
Dynamic Range (1 kHz):
90 dB
Harmonic Distortion:
0.01%
Channel Separation (1 kHz):
75 dB
10. SPECIFICATIONS
Audio
Maximum Power Output:
200 W (50 W 4 ch)
Continuous Average Power Output:
17 W 4, into 4 , 20 Hz to 20 kHz, 1%THD
Bass Control Action (60 Hz/80 Hz/120 Hz):
+14 dB, -12dB
Treble Control Action (8 kHz/12 kHz):
±12 dB
9 Band-G-EQ (63Hz to 16kHz)
1 oct step GAIN ± 12dB
Line Output Level (CD 1 kHz):
1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption:
Less than 15 A, 3A
Speaker Impedance:
4 (4 to 8 allowable)
Weight / Source unit:
5.06 lb. (2.3 kg)
Weight / Remote control unit:
1.41 oz. (40g) (including battery)
Dimensions / Source unit:
7” (Width) 4” (Height) 6-5/16” (Depth)
[178 (W) 100 (H) 160 (D) mm]
Dimensions / Remote control unit:
1-3/4”(Width) 4-7/16”(Height) 1/2”(Depth)
[44 (W) 113 (H) 13 (D) mm]
Note:
Specifications and design are subject to change without notice for further improvement.
