12 WXZ466MP
280-8171-00
English
Basic Operations
Adjusting the G.EQ EDIT
This function allows you to correct each fre-
quency band by 9 band equalizer.
This adjustment can only be performed when
the DZE is set to “DZE OFF”.
1. Press the [A-MODE] knob and select “G.EQ
EDIT”.
2. Turn the [SEARCH] knob to select the fre-
quency. (Adjustment range: 63Hz to 16kHz)
3. Turn the [A-MODE] knob to adjust the gain.
∗ The factory default setting is “0”. (Adjustment
range: -6 to +6)
4. Repeat steps 2 and 3 to adjust the gain and
the frequency.
Adjusting the bass (Gain, Frequency)
This adjustment can only be performed when
the DZE is set to “DZE OFF”.
1. Press the [A-MODE] knob and select
“BASS”.
2. Turn the [A-MODE] knob to adjust the bass.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +7)
3. Turn the [SEARCH] knob to select “BASS
FREQ”.
Turn the [A-MODE] knob to select the fre-
quency.
∗ The factory default setting is “60”. (Adjustment
60/80/120 Hz)
4. When the adjustment is complete, press the
[A-MODE] knob several times until the
function mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can only be performed when
the DZE is set to “DZE OFF”.
1. Press the [A-MODE] knob and select
“TREBLE”.
2. Turn the [A-MODE] knob to adjust the treble.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +6)
3. Turn the [SEARCH] knob to select
“TREBLE FREQ”.
Turn the [A-MODE] knob to select the fre-
quency.
∗ The factory default setting is “12k”. (Adjust-
ment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-MODE] knob several times until the func-
tion mode is reached.
Adjusting the balance
1. Press the [A-MODE] knob and select “BAL-
ANCE”.
2. Turn the [A-MODE] knob to adjust the bal-
ance of the left and right speakers.
∗ The factory default setting is “0”. (Adjustment
range: L13 to R13)
3. When the adjustment is complete, press the
[A-MODE] knob several times until the
function mode is reached.
Adjusting the fader
1. Press the [A-MODE] knob and select
“FADER”.
2. Turn the [A-MODE] knob to adjust the bal-
ance of the front and rear speakers.
∗ The factory default setting is “0”. (Adjustment
range: F12 to R12)
3. When the adjustment is complete, press the
[A-MODE] knob several times until the
function mode is reached.
