English
Radio Operations
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio sta-
tions in memory. Pressing the corresponding
[DIRECT] button recalls the stored radio fre-
quency automatically.
1. Press the [BAND] button and select the de-
sired band (FM or AM).
2. Press the corresponding [DIRECT] button to
recall the stored station.
∗ Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store that station
into preset memory.
Manual memory
1. Select the desired station with seek tuning,
manual tuning or preset tuning.
2. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
station into preset memory.
Auto store
Auto store is a function for storing up to 6 sta-
tions that are automatically tuned in sequen-
tially. If 6 receivable stations cannot be received,
a previously stored station remains
unoverwritten at the memory position.
1. Press the [BAND] button and select the de-
sired band (FM or AM).
2. Press and hold the [SEARCH] knob for 2
seconds or longer. The stations with good re-
ception are stored automatically to the preset
channels.
Listening to the radio
1. Turn the [SOURCE] knob and select the
radio mode. The frequency appears in the
display.
2. Press the [BAND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the follow-
ing order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1...
3. Turn the [SEARCH] knob to tune in the de-
sired station.
Tuning
There are 3 types of tuning modes available, seek,
manual and preset tuning.
Seek tuning
1. Press the [BAND] button and select the de-
sired band (FM or AM).
∗ If “MANU” is lit in the display, press and hold
the [BAND] button for 1 second or longer.
“MANU” in the display goes off and seek tun-
ing is now available.
2. Turn the [SEARCH] knob to automatically
seek a station.
When the knob is turned right, the station is
sought in the direction of higher frequencies;
if the knob is turned left, the station is sought
in the direction of lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the fre-
quency changes one step at a time. In the quick
tuning mode, you can quickly tune the desired
frequency.
1. Press the [BAND] button and select the de-
sired band (FM or AM).
∗ If “MANU” is not lit in the display, press and
hold the [BAND] button for 1 second or longer.
“MANU” is lit in the display and manual tuning
is now available.
2. Tune into a station.
●Quick tuning:
Turn the [SEARCH] knob for 1 second or
longer to tune in a station.
●Step tuning:
Turn the [SEARCH] knob to manually tune in
a station.
