32
DXZ575USB
TV Operations
Note:
• The following operations are performed the same
as for radio mode:
∗
Channel selection
∗
Storing channels in memory
∗
Calling channels from memory
∗
Auto store
∗
Preset scan
See “
Radio Operations
” (page 14-15) for details.
TV tuner functions
When an optional TV tuner is connected
through the CeNET cable, this unit controls all
TV tuner functions. To watch TV requires a TV
tuner and monitor.
Watching a TV
1. Press the [
SRC
] button and select the TV
mode.
2. Press the [
MENU
] button to select the
desired TV band (TV1 or TV2). Each time the
button is pressed, the input selection toggles
between TV1 and TV2.
3. Push the [
SEEK PANEL
] leftward or
rightward to tune in the desired TV station.
Watching a video
The TV tuner has a VTR input terminal to which
1 external device can be connected. Connect a
12 V video cassette player (VCP) or video
cassette recorder (VCR) to the TV tuner input
terminal.
1. Press the [
OPTION
] button.
2. Push the [
SEEK PANEL
] leftward or
rightward to select “
TV/VTR
”.
3. Press the [ ] button to enter the VTR
mode.
4. To return to the TV broadcast, press the
[
OPTION
] button.
5. Press the [ ] button to return to the
TV mode.
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
1. Press the [
OPTION
] button to switch to the
adjustment selection display.
2. Push the [
SEEK PANEL
] leftward or
rightward to select “
TV DIVER
”.
3. Press the [
UP
] or [
DN
] button to set to “
ON
”
or “
OFF
”.
• ON:
Sets the diver setting to ON.
• OFF:
Sets the diver setting to OFF.
4. Press the [
OPTION
] button to return to the
previous mode.
DXZ575USB_EN.book 32 ページ ２００６年１２月２５日 月曜日 午後１２時５７分
