Operations Common to Each Mode
English
23
DXZ575USB
●
Performing a system check
2-1. Select “
SYSTEM CHECK
”.
3-1. Press and hold the [ ] button for 1
second or longer.
“
SYSTEM CHECK
” appears in the display,
then the unit returns to the previous
operation mode.
AUX function
This system has an external input cable so you
can listen to sounds and music from external
devices connected to this unit.
●
Selecting AUX IN sensitivity
Make the following settings to select the
sensitivity when sounds from external devices
connected to this unit are difficult to hear even
after adjusting the volume.
∗
The factory default setting is “
MID
”.
1. Press the [
OPTION
] button, “
AUX SENS
MID
” appears in the display.
2. Press the [
UP
] or [
DN
] button to select
“
LOW
”, “
MID
” or “
HIGH
”.
3. Press the [
OPTION
] button to return to the
previous mode.
Entering titles
Titles up to 10 characters long can be stored in
memory and displayed for CD, CD changer and
TV stations. The number of titles that can be
entered for each mode are as follows.
1. Press the [
SRC
] button to select the mode
you want to enter a title (CD, CD changer or
TV).
2. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
enter the title.
3. Press the [
OPTION
] button.
4. Push the [
SEEK PANEL
] leftward or
rightward to select “
TITLE INPUT
”.
5. Press the [ ] button.
The display switches to the title input display.
6. Push the [
SEEK PANEL
] leftward or
rightward to move the cursor.
7. Press the [
MENU
] button to select a
character type. Each time you press the
[
MENU
] button, the character type changes
in the following order:
Capital letters
➜
Numbers
➜
Symbols
➜
Capital letters…
8. Press the [
UP
] or [
DN
] button to select the
desired character.
9. Repeat steps 6 to 8 to enter up to 10
characters for the title.
10.Press and hold the [ ] button for 2
seconds or longer to store the title into
memory.
Clearing titles
1. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
clear the title.
2. Press the [
OPTION
] button.
3. Push the [
SEEK PANEL
] leftward or
rightward to select “
TITLE INPUT
”.
4. Press the [ ] button.
The display switches to the title input display.
5. Press and hold the [
MENU
] button for 1
second or longer.
All characters in the title disappear.
6. Press and hold the [ ] button for 2
seconds or longer to store the setting.
Mode Number of titles
Radio mode 30 titles
CD mode 50 titles
TV mode 20 titles
CD changer mode Number of titles
DCZ625 connected 100 titles
