14
DXZ575USB
Radio Operations
Listening to the radio
1. Press the [
SRC
] button and select the radio
mode. The frequency appears in the display.
2. Press the [
MENU
] button and select the
radio band. Each time the button is pressed,
the radio reception band changes in the
following order:
FM1
➜
FM2
➜
FM3
➜
AM
➜
FM1...
3. Push the [
SEEK PANEL
] leftward or
rightward to tune in the desired station.
Tuning
There are 3 types of tuning mode available,
seek tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [
MENU
] button and select the
desired band (FM or AM).
2. Tune into a station.
∗
If “
MANU
” is lit in the display, press and hold
the [
MENU
] button for 1 second or longer.
“
MANU
” in the display goes off and seek
tuning is now available.
When the [
SEEK PANEL
] is pushed rightward,
the station is sought in the direction of higher
frequencies; if the [
SEEK PANEL
] is pushed
leftward, the station is sought in the direction of
lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the
frequency changes one step at a time. In the
quick tuning mode, you can quickly tune the
desired frequency.
1. Press the [
MENU
] button and select the
desired band (FM or AM).
∗
If “
MANU
” is not lit in the display, press and
hold the [
MENU
] button for 1 second or
longer. “
MANU
” is lit in the display and manual
tuning is now available.
2. Tune into a station.
●
Quick tuning
Push the [
SEEK PANEL
] leftward or rightward
and hold in position for 1 second or longer to
tune in a station.
●
Step tuning
Push the [
SEEK PANEL
] leftward or rightward
to manually tune in a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio
stations in memory. Pressing the [
UP
] or [
DN
]
button recalls the stored radio frequency
automatically.
1. Press the [
MENU
] button and select the
desired band (FM or AM).
2. Press the [
UP
] or [
DN
] button to recall the
stored station.
Manual memory
1. Select the desired station with seek tuning or
manual tuning.
2. Press the [ ] button to enter the
preset memory mode.
3. Press the [
UP
] or [
DN
] button to select a
desired station, then press and hold the
[] button for 2 seconds or longer to
store the current station into preset memory.
DXZ575USB_EN.book 14 ページ ２００６年１２月２５日 月曜日 午後１２時５７分
