Basic Operations
English
11
DXZ575USB
Adjusting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound
adjustment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
1. Press and hold the [ ] button for 1 second
or longer to turn on the MAGNA BASS
EXTEND effect. “
M-B EX
” lights in the
display.
2. Press and hold the [ ] button for 1 second
or longer to turn off the MAGNA BASS
EXTEND effect. “
M-B EX
” goes off from the
display.
∗
The adjustment can only be performed when
the DZE is set to “
DZE OFF
”.
∗
The factory default setting is off.
Mute
Use this function to turn off the sound
immediately.
1. Press the [ ] button.
The sound turns off and “
MUTE
” blinks in the
display.
2. Press the [ ] button again to cancel the
mute mode.
Adjusting Sound Mode
●
Adjusting the subwoofer output
volume
You can adjust the volume output from the unit’s
subwoofer output terminal.
2-1. Select the “
S-W VOL
”.
3-1. Press the [
UP
] or [
DN
] button to change the
output volume.
∗
The factory default setting is “
0
”.
(Setting range: +5 to –5)
To change sound mode
1. Press the [ ] button and select the sound
mode to adjust.
2. Push the [
SEEK PANEL
] leftward or
rightward to select the “item name”.
“
S-W VOL
”
↔
“
DZE
”
↔
“
BASS
”
↔
“
TREBLE
”
↔
“
S RESTOR
”
↔
“
HPF
”
↔
“
S-W LPF
”
↔
“
BALANCE
”
↔
“
FADER
”
3. Press the [
UP
] or [
DN
] button to select the
“desired setting value”.
∗
In the case of display blinking “
ENT
”, you
can press the
[] button to adjust the
setting value.
∗
“
BASS
” and “
TREBLE
” can be adjusted
only when “
DZE
” is set to “DZE OFF” (page
12).
∗ After completing settings, press the
[]
button to return to the previous mode.
Note:
• During sound adjustment mode, if no
operation is performed for more than 10
seconds, this mode can be canceled and
return to the previous mode.
