B&K AVR507 SERIES 2 Stereo Receiver User Manual



OPERATION & CONTROL
49
PRESETS
Saving a user preset is like taking a virtual picture of ALL USER settings in the receiver. This preset may
then be recalled at any time. Up to 40 presets may be saved in either the main theater zone or the second
zone. Presets provide a powerful method to recall favorite settings. Presets are easily recalled from the
SR10.1 remote control. The parameters that may be saved with a preset are:
Audio Source Speaker Selection Center channel volume
Video Source Radio Station Subwoofer volume
Audio Mode User EQ Rear channels volume
Volume Record Loop
Preset titles can be customized according to the preset function. The following steps outline the procedure to
save a preset.
Quick Preset Outline
- Set the unit exactly for the desired user settings. Press the SAVE button. Then select
the preset number you want to save it to. Press ENTER to save the settings. To recall a preset, press the
preset number, then ENTER.
Saving a Preset
The following steps detail the procedure that is used to setup and save a preset. The procedure references
the SR10.1 Remote Control that came with the AVR507 Series2 or AVR507 Series2 receiver.
Step 1
First, setup the receiver for the desired speaker selection, input, volume level and/or EQ. The Z1 or Z2
Operation Menu is helpful when setting up system parameters. It is accessed from the first page of the On
Screen Setup menu.
Step 2
From the SR10.1 remote, press the B& K button in the upper left corner of the remote screen. Then press
the PAGE button two times. In the lower left corner of Page 3, you will see the SAVE button. Press the
SAVE button one time. Pressing the SAVE button will activate the on screen display. The on screen display
will show the settings of the preset that is about to be saved. If a preset is saved from the front panel,
pressing ENTER and PRESET at the same time acts like the SAVE button.
ON OFF
MAIN
FAV
VOL CH
MUTE
PREV
CH
GUIDE
PAGE
+
_
_
+
MAIN
B&K SAT
DVD CD
TAPE TV
V1 V2
FM AM
PAGE 1
ON OFF
MAIN
FAV
VOL CH
MUTE
PREV
CH
GUIDE
PAGE
+
_
_
+
B&K
DVD SAT
CD TV
V1 V2
FM AM
TAPE Z
PAGE 1
ON OFF
MAIN
FAV
VOL CH
MUTE
PREV
CH
GUIDE
PAGE
+
_
_
+
B&K
IMG- IMG+
DIM- DIM+
PAN- PAN+
MUSIC MOVIE
SAVE EQ
PAGE 3
