STR-DA1800ES
4-428-194-12(2)
a)
You can select this setting only when you have performed the Auto Calibration and saved the settings.
b)
Depends on the speaker pattern setting, some parameters or settings may not be available.
c)
xxx represent a speaker channel (FL, FR, CNT, SL, SR, SB, SBL, SBR, LH, RH, SW).
d)
You can only select this parameter if “SP PATTERN” is not set to a setting with surround back or front high
speakers (page 42).
e)
You can only adjust the distance in 0.01 meter interval when you have performed the Auto Calibration and
saved the measurement result.
f)
You can only select this parameter if your speaker is set to “SMALL”.
g)
You can only select this parameter if you select “HD-D.C.S.” as sound field.
h)
You can only select this parameter when a Bluetooth device is paired.
System settings
[<SYSTEM>]
12V Trigger control
[12V TRIG.]
HDMI A, HDMI B, INPUT, ZONE,
CTRL, OFF
OFF
RS232 control
[RS232C]
RS232C ON, RS232C OFF RS232C OFF
Auto standby mode
[AUTO STBY]
STBY ON, STBY OFF STBY ON
Naming inputs
[NAME IN]
For details, see “Naming the input
(Name Input)” (page 55).
Menu
[Display]
Parameters
[Display]
Settings Default
setting
