Advanced Tuner Operations
1234567890ABCDEF
GHIJKLMNOPQ6-_3S
If you cannot tune in the station you want
(Manual Tuning)
With manual tuning you can search through all
stations broadcasting on each band, and tune in
stations with extremely weak signals that you might
not be able to receive with automatic tuning.
1 Press DAB, FM or AM for the desired type of
broadcast.
2 Press TUNING MODE so that neither “AUTO”
nor “PRESET” appear in the display.
3 Turn TUNING/SELECT until you tune in the
station you want.
Turn the control to the right for a higher
frequency; turn it to the left for a lower frequency.
z Listening to a secondary component of the DAB
programme Z
When “SC” appears in the display while listening to a
DAB programme, a secondary component is contained
in the current service.
Press MONO/SC so that the desired secondary
component is received.
Display window while receiving the secondary
component (automatic/manual tuning mode)
When you receive the secondary component in the
preset tuning mode, the secondary service label appears
in the display window.
Storing Stations Manually
This section shows you how to store up to 99 of your
favorite DAB, FM or AM (MW and LW) stations
manually onto preset numbers.
You can assign the preset number to the desired station
from 1 for each broadcast band (DAB, FM and AM) up
to a combined total of 99 stored stations.
1 Press DAB, FM or AM for the desired type of
broadcast.
2 Press TUNING MODE repeatedly so that the
tuner is set to automatic or manual tuning mode.
3 Turn TUNING/SELECT to tune in the station you
want to store.
4 Press MEMORY.
“MEMORY” appears along with the lowest vacant
number to indicate that the tuner is ready to store
the station.
5 Press ENTER.
The tuner stores the station at the preset number.
6 Repeat steps 1 through 5 to store other stations.
If you want to preset the station to an already
assigned number
Turn TUNING/SELECT so that the desired number
appears after performing step 4 above. In this case, the
previously preset station is replaced with the new one.
z DAB and RDS Station names are stored
automatically
When you preset a DAB or RDS station that is
broadcasting station name information, the station
name is automatically stored at the station preset.
z If you want to label the stations
Follow the procedure described in “Naming the Preset
Stations” on page 12.
z When you tune in AM (MW and LW) stations
Adjust the direction of the AM loop aerial for optimum
reception.
DAB, FM, AM TUNING/SELECT
TUNING MODE ENTER
MEMORY
Number of services in
the current ensemble
Current service number
Indicates the secondary service.
While receiving the primary service,
“P” appears.
