Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 67 —
C805 1-130-781-00 FILM 0.22uF 10% 100V
C806 1-130-781-00 FILM 0.22uF 10% 100V
C807 1-128-555-91 ELECT 470uF 20% 63V
C808 1-126-967-11 ELECT 47uF 20% 50V
C809 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
CNP801 1-785-102-21 PIN, CONNECTOR 4P
CNP802 1-785-102-11 PIN, CONNECTOR 4P
* CNP803 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
CNP804 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D801 8-719-072-05 DIODE RBV-602LF-A
D806 8-719-070-30 DIODE PTZ-TE25-5.6A
D810 8-719-074-75 DIODE PTZ-TE25-30B
< EARTH >
* EB801 1-537-738-21 TERMINAL, EARTH
< FUSE >
!F801 1-533-311-11 FUSE, GLASS CYLINDRICAL(DIA.5) 8A/125V
!F802 1-533-311-11 FUSE, GLASS CYLINDRICAL(DIA.5) 8A/125V
< TRANSISTOR >
Q801 8-729-048-78 TRANSISTOR 2SD1733-TL-QR
< RESISTOR >
!R801 1-247-727-11 CARBON 10 5% 1/2W F
!R802 1-249-401-11 CARBON 47 5% 1/4W F
R803 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R804 1-216-081-00 METAL CHIP 22K 5% 1/10W
************************************************************
A-4419-440-A DIGITAL BOARD, COMPLETE
(DE835:US,CND/SE591)
***********************
A-4419-441-A DIGITAL BOARD, COMPLETE (DE935)
***********************
A-4426-046-A DIGITAL BOARD, COMPLETE
(DE835:E,PX,SP,MY,AUS/V828)
***********************
< CAPACITOR >
C1001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1002 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1003 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1004 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1005 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1006 1-128-834-11 ELECT 470uF 20% 10V
C1007 1-128-858-11 ELECT 22uF 20% 50V
C1008 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1009 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1010 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C1011 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1012 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1013 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1014 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1015 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1016 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1017 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1018 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1019 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1020 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1031 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(DE935)
C1101 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1102 1-128-840-11 ELECT 47uF 20% 16V
C1103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1104 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1105 1-128-840-11 ELECT 47uF 20% 16V
C1106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1107 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1109 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1110 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1156 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1157 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1201 1-119-824-11 ELECT MELF 10uF 20% 50V
C1202 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1203 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1204 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1205 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1206 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1207 1-128-840-11 ELECT 47uF 20% 16V
C1208 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1210 1-128-840-11 ELECT 47uF 20% 16V
C1211 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1212 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1213 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1214 1-128-840-11 ELECT 47uF 20% 16V
C1215 1-127-720-91 ELECT MELF 470uF 20% 16V
C1216 1-127-720-91 ELECT MELF 470uF 20% 16V
C1217 1-127-720-91 ELECT MELF 470uF 20% 16V
C1218 1-126-959-11 ELECT 0.47uF 20% 50V
C1219 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1220 1-126-957-11 ELECT 0.22uF 20% 50V
C1221 1-119-824-11 ELECT MELF 10uF 20% 50V
C1222 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1223 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1225 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1226 1-126-960-11 ELECT 1uF 20% 50V
DC DIGITAL
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
