Getting Started – ADVANCED –
23
US
1 Prepare screws (not supplied) that are
suitable for the hole on the back of
each speaker. See the illustrations
below.
2 Fasten the screws to the wall.
For the center speaker
For the other speakers
3 Hang the speakers on the screws.
Note
• Use screws that are suitable for the wall material and
strength. As a plaster board wall is especially fragile,
attach the screws securely to a beam and fasten them
to the wall. Install the speakers on a vertical and flat
wall where reinforcement is applied.
• Contact a screw shop or installer regarding the wall
material or screws to be used.
• Sony is not responsible for accident or damage
caused by improper installation, insufficient wall
strength or improper screw installation, natural
calamity, etc.
Installing the Speakers on
a Wall
30 mm (1
3
/
16
inch)
4 mm (
5
/
32
inch)
Hole on the back of
the speaker
4.6 mm
(
3
/
16
inch)
10 mm
(
13
/
32
inch)
8 to 10 mm
(
11
/
32
to
13
/
32
inch
)
160 mm
(
6
3
/
8
inch
)
8 to 10 mm
(
11
/
32
to
13
/
32
inch
)
4.6 mm
(
3
/
16
inch)
10 mm
(
13
/
32
inch)
