Sound Bar (SA-CT660)
Amplifier section
U.S. models:
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both channels
driven, from 200 - 20,000 Hz; rated
25 Watts per channel minimum RMS
power, with no more than 1 % total
harmonic distortion from 250
milliwatts to rated output.
POWER OUTPUT (reference)
Front L/Front R: 100 W
(per channel at 3 ohms, 1 kHz)
Canadian models:
POWER OUTPUT (rated)
Front L + Front R: 35 W + 35 W
(at 3 ohms, 1 kHz, 1 % THD)
POWER OUTPUT (reference)
Front L/Front R: 100 W (per channel
at 3 ohms, 1 kHz)
Inputs
HDMI IN 1/2/3
ANALOG IN
OPTICAL IN
Output
HDMI TV OUT (ARC)
BLUETOOTH section
Communication system
BLUETOOTH Specification version
3.0
Output
BLUETOOTH Specification Power
Class 2
Maximum communication range
Line of sight approx. 10 m
1)
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread
Spectrum)
Compatible BLUETOOTH profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported Codecs
3)
SBC
4)
, AAC
5)
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling
frequency 44.1 kHz)
1) The actual range will vary depending
on factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone, reception sensitivity,
operating system, software
application, etc.
2) BLUETOOTH standard profiles
indicate the purpose of BLUETOOTH
communication between devices.
3) Codec: Audio signal compression and
conversion format
4) Subband Codec
5) Advanced Audio Coding
Front speaker unit
Speaker system
2-way speaker system, Acoustic
suspension
Speaker unit
Woofer: 50 mm × 90 mm
(2 in × 3 5/8 in) cone type
Tweeter: 20 mm (13/16 in) balance
drive type
Rated impedance
3 ohms
General
Power requirements
120 V AC, 60 Hz
Power consumption
On: 34 W
“Control for HDMI” is off (Standby
mode): 0.3 W or less
BLUETOOTH Standby mode: 0.5 W
or less
Dimensions (approx.)
1,030 mm × 109 mm × 94 mm
(40 5/8 in × 4 3/8 in × 3 3/4 in) (with
stands)
1,030 mm × 95 mm × 107 mm
(40 5/8 in × 3 3/4 in × 4 1/4 in)
(without stands)
continued
