36
GB
The Setup Display for selecting the
language used in the on-screen display
appears.
5 Press X/x to select a language.
The system displays the menu and subtitles
in the selected language.
• The selectable language is different depending
on the area.
6 Press ENTER.
The Setup Display for selecting the aspect
ratio of the TV to be connected appears.
7 Press X/x to select the setting that
matches your TV type.
x If you have a 4:3 standard TV
[4:3 LETTER BOX] or [4:3 PAN SCAN]
(page 85)
x If you have a wide-screen TV or a 4:3
standard TV with a wide-screen mode
[16:9] (page 85)
8 Press ENTER.
The Setup Display for selecting the output
method for video signals from the EURO
AV T OUTPUT (TO TV) jack on the rear
panel of the system appears.
9 Press X/x to select the output method
for video signals.
• [VIDEO]: outputs video signals.
• [RGB]: outputs RGB signals.
• If your TV does not accept RGB signals, no
picture appears on the TV screen even if you
select [RGB]. Refer to the instructions supplied
with your TV.
10Press ENTER.
The Setup Display for selecting the speaker
distance appears.
11Press X/x to select the front speaker
distance from the listening position,
then press ENTER.
You can set from 1.0 to 7.0 meters (4 to 23
ft).
12Press X/x to select the center speaker
distance from the listening position,
then press ENTER.
You can set from 0.0 to 7.0 meters (0 to 23
ft).
• The setting range changes depending on the
front speaker setting.
Note
LANGUAGE SETUP
OSD:
MENU:
AUDIO:
SUBTITLE:
PORTUGUESE
FRENCH
ENGLISH
ENGLISH
SPANISH
SCREEN SETUP
TV TYPE:
16:9
4:3 PAN SCAN
4:3 LETTER BOX
FULL
SCREEN SAVER:
LINE:
BACKGROUND:
4:3 OUTPUT:
16:9
Note
Note
SCREEN SETUP
SCREEN SAVER:
4:3 OUTPUT:
BACKGROUND:
LINE:
VIDEO
VIDEO
RGB
TV TYPE:
16:9
ON
JACKET PICTURE
SPEAKER SETUP
TEST TONE:
LEVEL(FRONT):
LEVEL(SURROUND):
OFF
CENTER:
3.0m
3.0m
SURROUND:
DISTANCE:
SIZE:
FRONT:
3.0m
SPEAKER SETUP
TEST TONE:
LEVEL(FRONT):
LEVEL(SURROUND):
OFF
3.0m
3.0m
SURROUND:
DISTANCE:
SIZE:
FRONT:
CENTER:
3.0m
