SPECIFICATIONS
Decoding formats Dolby Digital, Dolby Pro Logic,
DTS, THX Surround EX
Sampling rates 32kHz, 44.1kHz, 48kHz, 96kHz
Modes EARS
STEREO (ANALOG BYPASS)
Analog input impedance 16k/ 100pF
Analog frequency response 20Hz - 20kHz +/- 0.2dB
Maximum input level 3V rms
THD+N 0.005%
Signal/noise ratio >90dB
Dynamic range 95dB
Analog channel separation >95dB
Crosstalk >90dB
Maximum output level 6V rms
OUTPUT IMPEDANCE
Main pre-out 56
Tape out 470
Multi room output 470
TONE CONTROL
Bass (@20Hz) +/- 12dB
Treble (@20kHz) +/- 12dB)
DIGITAL INPUT PERFORMANCE
THD+N (Bandwidth 10Hz - 20kHz) 0.005%
Digital input impedance 75
VIDEO
Input and output impedance 75
PHYSICAL SPECIFICATIONS
Size (W x H x D) 17 3/4 x 3 7/8 x 11 1/4"
450 x 97 x 285 mm
Net weight 11 lbs (4.99kg)
Shipping weight 13 lbs (5.89kg)
