7. TONE DEFEAT
The TONE DEFEAT switch by-passes the tone control section of the
NAD C340. If the Tone Controls are not normally used and left in
the 12 o’clock position, then it is advisable to switch out the Tone
Control section altogether by using this switch. In the ‘out’
position, the Tone Control circuits are active, pushing the TONE
DEFEAT switch ‘in’ bypasses the Tone Control section.
8. BALANCE
The BALANCE control adjusts the relative levels of the left and right
speakers. The 12 o’clock position provides equal level to the left
and right channels. A detent indicates this position.
Rotating the control clockwise moves the balance towards the
right. Rotating the control anti-clockwise moves the balance to the
left. The BALANCE control does not affect recordings made using
the Tape outputs but will affect the signal going to the Pre-amp
output (Pre Out).
9. VOLUME
The VOLUME control adjusts the overall loudness of the signals
being fed to the loudspeakers. It is motor driven and can be
adjusted from the remote control handset. The VOLUME control
does not affect recordings made using the Tape outputs but will
affect the signal going to the Pre-amp output (Pre Out).
On the remote control handset, press the MUTE Button to
temporarily switch off the sound to the speakers and headphones.
Mute mode is indicated by the active input LED flashing. Press
MUTE again to restore sound. Mute does not affect recordings
made using the Tape outputs but will affect the signal going to the
Pre-amp output (Pre Out).
TO MAKE A RECORDING
When any source is selected, its signal is also fed directly to any
tape machine connected to the TAPE 1 or TAPE 2 OUTPUTS for
recording.
TAPE TO TAPE COPYING
You can copy between two tape machines connected to your NAD
C340. Put the source tape in the recorder connected to Tape 1 and
the blank tape into the recorder connected to Tape 2. By selecting
TAPE 1 Input you can now record from Tape 1 to Tape 2 and
monitor the signal coming from the original tape.
REMOTE CONTROL HANDSET
The Remote Control handset handles all the key functions of the
NAD C340 and has additional controls to remotely operate NAD
Tuners, Cassette and CD machines. It will operate up to a distance
of 16ft (5m).
Alkaline batteries are recommended for maximum operating life.
Two AAA (R 03) batteries should be fitted in the battery
compartment at the rear of the Remote Control handset. When
replacing batteries, check that they have been put in the right way
round, as indicated on the base of the battery compartment.
Please refer to previous sections of the manual for a full
description of individual functions.
NOTE: The remote control handset supplied with the C340 is of a
universal NAD type, designed to operate several NAD models.
Some buttons on this handset are inoperative as the functions
aren’t supported by the C340.
The Stand-by (large green button) function, Video 2 and Video 3
input selector, and Speakers A and Speakers B buttons on the
remote control handset are inoperative in the case of the C340.
The input selector buttons perform the same functions as the
buttons labelled the same on the front panel. There are a few
differences and extra functions with the remote control handset
however:
TUNER AM, TUNER FM
Selects the Tuner input on the NAD C340 and respectively the AM
or FM waveband on a separate remote controllable NAD Tuner.
MUTE
Press the MUTE Button to temporarily switch off the sound to the
speakers and headphones. Mute mode is indicated by the active
input LED flashing. Press MUTE again to restore sound. Mute does
not affect recordings made using the Tape outputs but will affect
the signal going to the Pre-amp output (Pre Out).
MASTER VOLUME
or respectively increases or decreases the Volume
setting. The motorised Volume Control on the front panel will
indicate the level set.
Other than the commands relating to the NAD C340 amplifier
itself, there are other buttons which will operate most NAD CD
players and Cassette decks equipped with NAD Link:
TUNER CONTROL
(for use with NAD Tuner)
BANK Selects a bank of preset stations.
PRESET or selects respectively higher or lower
number station preset.
CD PLAYER CONTROL
(for use with NAD CD Player)
engages Pause
engages Stop
engages Play or toggles between Play and Pause
or engages Track skip; Press once to respectively go to
the next track or to return to start of current or previous track.
NEXT DISC Go to next disc (for NAD CD changers).
CASSETTE DECK CONTROL
(For use with single (DECK B) or double transport (A and B) NAD
Cassette Decks)
or engages Forward Play or Reverse Play.
Record / Pause. Press to put cassette deck into record-
pause. Press Play to start recording.
Stops Play or Recording.
engages Rewind.
engages Fast Forward.
NOTE: Direct sunlight or very bright ambient lighting may affect
the operating range and angle for the remote control handset.
