Preparation section
17
Operation of the remote control unit
Loading batteries
1 Remove the cover. 3 Close the cover.
÷ Insert two R6 (“AA”-size) batteries
following the polarity indications.
2 Insert batteries.
Operation
Plug the power cord into the mains power outlet and
press the POWER (
) key of the remote control unit
to turn the power ON. After the power has been turned
ON, press the desired key.
To put the power in standby, press the POWER ( ) key
again. The power mode enters the standby mode and
the STANDBY indicator lights up.
÷ When pressing more than one remote control key
successively, press the keys securely and leave an
interval of 1 second or more between the key presses.
1.The provided batteries are intended for use in operation checking, and their service life may be short.
2.When the remote controllable distance becomes short, replace both of the batteries with new ones.
3.If direct sunlight or the light of a high-frequency fluorescent lamp (inverter type, etc.) is incident to the remote
sensor, malfunction may occur. In such a case, change the installation position to avoid malfunction.
Operating range
(approx.)
Remote
sensor
Notes
Notes
30
˚
6m
30
˚
