JVC XT-UXG66 Stereo System User Manual



4
Front Panels
AX-UXG66 Stereo Amplifier
1 button and STANDBY/ON lamp (11)*
2 MULTI JOG dial
3 FM/AM button (14)*
4 OPEN/CLOSE button (13)*
5 Display window
6 VOLUME dial (11)
7 AUX button (13, 24)*
XT-UXG66 Compact Disc/Tuner
8 CD tray
9 Remote sensor (5)
p PHONES jack (12)
q 0 (open/close) button for CD tray (16)*
w 6 (play/pause) button (17)*
e 7 (stop) button (17)
TD-UXG66 Cassette Deck
r π (auto-reverse) button and lamp (20, 23)
t DOLBY B NR button and lamp (21, 23)
y REC PAUSE button (22)
u Tape operations indicators (20, 22)
Tape direction (2 / 3) and REC indicators
i 0 (open/close) button for Tape tray (20)*
o
` (playback) button (20)*
; 7 (stop) button (21)
a Tape tray
To press the buttons suffixed with * mark also
turns on the system.
Display window
1 Timer mode indicators
REC (recording timer) and
DAILY (daily
timer) indicators
2 CD playback mode indicators
PROGRAM, RANDOM,
(repeat 1),
and
(repeat all) mode indicators
3 FM mode indicators
STEREO and MONO indicators
4 BASS indicator
Buttons behind the sliding panel
1 DISPLAY/CHARA. button **
2 4 button (14, 17, 18, 21)
3 ¢ button (14, 17, 18, 21)
4 SET button (18, 25)
5 CANCEL button (10, 18, 25)
6 ENTER button **
7 PLAY MODE button (17)
8 REC MODE button (24)
9 TITLE/EDIT button **
p CLOCK/TIMER button (10, 25)
** Used only with MiniDisc recorder XM-G6
(not supplied).
DO NOT operate any button and control until
the system setup is completed.
DO NOT operate the sliding panel by hands,
otherwise it will cause serious damages on the
sliding mechanism (see page 13).
Continued
MOS - FET
DISPLAY
/CHARA.
PLAY
MODE
REC
MODE
TITLE
/EDIT
CLOCK
/TIMERCANCEL ENTER
12345
