20
DO NOT try to open or close the tape tray by
hands as it will be damaged.
DO NOT place any foreign matters.
DO NOT prevent the tray from opening and
closing, because it may results damages on the
unit.
3
Press 0 (open/close) button again to close the tray.
4
Press ` (playback) button on the unit or TAPE
` (playback) button on the remote control.
The tape playback starts and the tape direction indicator
blinks slowly in orange to show the tape running
direction.
Each time you press ` (playback) on the cassette
deck unit or TAPE ` (playback) button on the remote
control, you can change the tape sides to be played
back currently.
3 : plays the forward side.
2 : plays the reverse side.
Playback comes to an end (Auto Reverse)
The cassette deck unit automatically changes the tape
direction to the reverse side, and continue playback
both sides. Each time to press the button, Auto
Reverse feature is set to on/off alternately.
You can listen to Normal (Type I), High position (TypeII),
and Metal (Type IV) type tapes without further settings.
When using the inner buttons, press OPEN/CLOSE button
on AX-UXG66 6unit to open the sliding panel first.
When using the remote control, press TAPE 23
(playback) button first and 7 (stop) button successively.
DO NOT use tapes longer than 120 minutes.
The characteristic deterioration may occur and these
tapes easily jam in the tape transport mechanism.
Playing Back a Tape — Basic Operation
1
Press 0 (open/close) button on the cassette deck
unit.
The system automatically turns on and the tape tray
comes out.
2
Place a tape on the tray with the side you want to
listen to facing up (forward side).
Tape fits in the caved-in area so that an exposed edge
of the tape faces toward the inside of the unit.
Playing Back a Tape
REC PAUSE
DOLBY B NR
AUTO
REVERSE
REC
DOLBY B NR
π (auto reverse)
0 (open/close)
` (playback)
7 (stop)
Tape operation indicators
DISPLAY
/CHARA.
PLAY
MODE
REC
MODE
TITLE
/EDIT
CLOCK
/TIMERCANCEL ENTER
SET
4 ¢
Buttons behind the sliding panel
4 ¢
REC
Tape direction indicator
VOLUME
MD
CANCEL
DISPLAY
/CHARA.
><
TAPE
FM/AM
DOWN
SET
UP
AUX
CD
4 / ¢
7 (stop)
TAPE ` (playback)
